Запчасти Komatsu D39E-1A FIG. T-A ОТВАЛ И ANGLING РАМА - D9P-A РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

1270 125 H95

BLADE AND ANGLING FRAME

SN: P096338--UP

1шт.

1

620 693 C2

PIN, BLADE TO ANGLING FRAME

SN: P096338--UP

1шт.

2

1267 333 H1

SHIM, LOWER RETAINER PLATE

SN: P096338--UP

-2шт.

3

1267 334 H1

PLATE LOWER RETAINER

SN: P096338--UP

2шт.

|$4

24 890 R1

BOLT, HEX - 3/4NCx2-1/2

SN: P096338--UP

6шт.

4

1267 332 H1

PLATE, UPPER RETAINER

SN: P096338--UP

2шт.

|$6

24 890 R1

BOLT, HEX - 3/4NCx2-1/2

SN: P096338--UP

10шт.

5

1267 331 H1

SHIM, UPPER RETAINER PLATE

SN: P096338--UP

-2шт.

6

FRAME ASSEMBLY, BLADE ANGLING (SEE FIG. T2110-02A2)

SN: P096338--UP

1шт.

|$9

1270 126 H94

BLADE ASSEMBLY, DOZER

SN: P096338--UP

1шт.

|$10

1270 127 H94

BLADE SUB ASSEMBLY

SN: P096338--UP

1шт.

7

NSS

BLADE, DOZER

SN: P096338--UP

1шт.

8

1282 813 H2

PLATE, WEAR

SN: P096338--UP

2шт.

9

1282 814 H2

PLATE, WEAR

SN: P096338--UP

1шт.

10

705 734 C1

BUSHING, PIN

SN: P096338--UP

1шт.

11

1282 468 H1

EDGE, INNER CUTTING

SN: P096338--UP

2шт.

|$16

646 534 C1

BOLT, PLOW

SN: P096338--UP

10шт.

|$17

25 529 R1

NUT, HEX - 3/4NC

SN: P096338--UP

10шт.

12

1268 300 H1

EDGE, OUTER CUTTING

SN: P096338--UP

2шт.

|$19

646 534 C1

BOLT, PLOW

SN: P096338--UP

10шт.

|$20

25 529 R1

NUT, HEX - 3/4NC

SN: P096338--UP

10шт.

13

1268 300 H1

BEARING, NON-LUBE

SN: P096338--UP

1шт.

14

1268 301 H1

SEAL, PIN

SN: P096338--UP

2шт.

|$23

-1шт.

|$24

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$25

-1шт.

|$26

-1шт.

|$27

F2 - MINIMUM OF 1 SHIM TO A MAXIMUM OF 6 SHIMS LOCATED PER SIDE.

-1шт.

|$28

-1шт.

|$29

-1шт.

|$30

F3 - MINIMUM OF 2 SHIM TO A MAXIMUM OF 7 SHIMS LOCATED PER SIDE.

-1шт.

|$31

-1шт.
