Запчасти Komatsu D39E-1A FIG. T-A ОТВАЛ ОБОРУД-Е - D9P-A РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

1315 093 H91

BLADE EQUIPMENT

SN: P096338--UP

1шт.

|$1

1262 850 H91

DOZER CYLINDERS

SN: P096338--UP

1шт.

1

CYLINDER, LIFT (SEE FIG. T2170-01A0)

SN: P096338--UP

2шт.

2

CYLINDER, ANGLE (SEE FIG. T2190-01A0)

SN: P096338--UP

2шт.

3

CYLINDER, TILT (SEE FIG. T2180-01A0)

SN: P096338--UP

1шт.

4

1270 112 H1

PIN, MOUNTING

SN: P096338--UP

9шт.

|$6

24 856 R1

BOLT, HEX - 7/16NCx4

SN: P096338--UP

9шт.

|$7

9413 981

NUT, LOCK - 7/16NC

SN: P096338--UP

9шт.

5

1279 088 H1

PIN, MOUNTING

SN: P096338--UP

1шт.

|$9

24 856 R1

BOLT, HEX - 7/16NCx4

SN: P096338--UP

1шт.

|$10

9413 981

NUT, LOCK - 7/16NC

SN: P096338--UP

1шт.

|$11

1262 760 H91

TRUNNIONS

SN: P096338--UP

1шт.

6

1280 387 H91

TRUNNION, LEFT

SN: P096338--UP

1шт.

|$13

25 646 R1

BOLT, HEX - 1NCx2-3/4

SN: P096338--UP

4шт.

|$14

25 550 R1

WASHER, FLAT - 1

SN: P096338--UP

4шт.

7

1280 388 H91

TRUNNION, RIGHT

SN: P096338--UP

1шт.

|$16

25 646 R1

BOLT, HEX - 1NCx2-3/4

SN: P096338--UP

4шт.

|$17

25 550 R1

WASHER, FLAT - 1

SN: P096338--UP

4шт.

8

1279 063 H1

PIN, C-FRAME

SN: P096338--UP

2шт.

|$19

24 880 R1

BOLT, HEX - 5/8NCx3-1/2

SN: P096338--UP

2шт.

|$20

9412 231

NUT, LOCK - 5/8NC

SN: P096338--UP

2шт.

9

1209 358 H1

SHIM, FRAME - 0.090IN

SN: P096338--UP

-2шт.

10

BLADE AND ANGLING FRAME (SEE FIG. T2110-02A1)

SN: P096338--UP

1шт.

11

1270 296 H91

PIN, LOCK

SN: P096338--UP

1шт.

|$24

24 859 R1

BOLT, HEX - 1/2NCx3/4

SN: P096338--UP

1шт.

|$25

932 278 C1

WASHER, FLAT - 1-3/8

SN: P096338--UP

1шт.

12

1209 358 H1

SHIM, FRAME - 0.090IN

SN: P096338--UP

-2шт.

13

1209 358 H1

SHIM, FRAME - 0.090IN

SN: P096338--UP

1шт.

14

1209 358 H1

SHIM, FRAME - 0.090IN

SN: P096338--UP

2шт.

15

FRAME, C (SEE FIG. T2110-03A0)

SN: P096338--UP

1шт.

16

BAR, C FRAME RUB (SEE FIG. R0500-01A2)

SN: P096338--UP

2шт.

|$31

-1шт.

|$32

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$33

-1шт.

|$34

-1шт.

|$35

F2 - MINIMUM 1 SHIM TO MAXIMUM 2 SHIMS USED AT THIS POSITION.

-1шт.

|$36

-1шт.
