Запчасти Komatsu D39E-1A FIG. R-A ГУСЕНИЦЫ РЕГУЛЯТОР ХОДОВАЯ

1

621 447 C1

FORK, FRONT IDLER - CAST

SN: P096338-UP

2шт.

|$2

OR

-1шт.

|$4

1299 266 H91

FORK, FRONT IDLER - WELDED

SN: P096338-UP

2шт.

|$5

24 863 R1

BOLT, HEX 1/2NCx13/4

SN: P096338-UP

8шт.

|$6

116 121

WASHER, LOCK 1/2

SN: P096338-UP

8шт.

2

319 628 R91

VALVE, ADJUSTER CHECK

SN: P096338-UP

2шт.

3

109 461

FITTING, LUBE

SN: P096338-UP

2шт.

4

662 799 C1

PLUG, ADJUSTER BLEEDER

SN: P096338-UP

2шт.

|$11

OR

-1шт.

|$13

635 286 C91

PLUG, ADJUSTER BLEEDER

SN: P096338-UP

2шт.

|$14

50 410 DA

PLUG, PORT

SN: P096338-UP

1шт.

|$15

319 628 R91

VALVE, CHECK

SN: P096338-UP

1шт.

5

621 430 C1

SHIELD, ADJUSTER

SN: P096338-UP

2шт.

|$17

24 862 R1

BOLT, HEX 1/2NCx1-1/2

SN: P096338-UP

4шт.

|$18

116 121

WASHER, LOCK 1/2

SN: P096338-UP

4шт.

|$19

622 825 C91

KIT, PISTON SEAL

SN: P096338-UP

2шт.

6

NSS

WIPER, ROD

SN: P096338-UP

1шт.

7

NSS

RING, PISTON

SN: P096338-UP

1шт.

8

622 049 C1

PISTON, ADJUSTER

SN: P096338-UP

2шт.

9

1280 469 H1

ROD, TRACK ADJUSTER

SN: P096338-UP

2шт.

10

621 453 C1

RETAINER, TRACK SPRING

SN: P096338-UP

4шт.

11

621 452 C2

SPRING, TRACK

SN: P096338-UP

2шт.

12

1280 545 H1

PLATE, SCRAPER

SN: P096338-UP

2шт.

|$27

-1шт.

|$28

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$29

-1шт.
