Запчасти Komatsu D39E-1A FIG. M-A КАПОТ, ПАНЕЛЬS, СУППОРТS И DASH - КАБИНА ROPS ЧАСТИ КОРПУСА

1

1304 451 H92

DASHBOARD

SN: P096338-UP

1шт.

|$1

24 861 R1

BOLT, HEX - 1/2NCx1-1/4

SN: P096338-UP

6шт.

|$2

25 546 R1

WASHER, FLAT - 1/2

SN: P096338-UP

6шт.

2

1286 760 H2

SHIM, MOUNTING

SN: P096338-UP

-2шт.

3

1308 145 H1

BAR, DASH BRACE

SN: P096338-UP

2шт.

|$5

24 860 R1

BOLT, HEX - 1/2NCx1

SN: P096338-UP

4шт.

|$6

25 546 R1

WASHER, FLAT - 1/2

SN: P096338-UP

4шт.

4

COWL, DASH (SEE FIG. K0210-01A0)

SN: P096338-UP

1шт.

5

27 951 R1

PLUG, FRONT LIGHTS BUTTON

SN: P096338-UP

4шт.

6

HOOD, SOLID (SEE FIG. M2140-02A0)

SN: P096338-UP

1шт.

|$10

24 859 R1

BOLT, HEX - 1/2NCx3/4

SN: P096338-UP

3шт.

|$11

106 265

WASHER, FLAT - 9/16

SN: P096338-UP

3шт.

|$13

OR

-1шт.

|$15

HOOD, PERFORATED (SEE FIG. M2140-02A1)

SN: P096338-UP

1шт.

|$16

24 859 R1

BOLT, HEX - 1/2NCx3/4

SN: P096338-UP

3шт.

|$17

106 265

WASHER, FLAT - 9/16

SN: P096338-UP

3шт.

7

DOOR, L.H. SIDE (SEE FIG. M2140-03A0)

SN: P096338-UP

1шт.

|$19

26 310 R1

BOLT, HEX - 3/8NCx1

SN: P096338-UP

3шт.

|$20

25 553 R1

WASHER, FLAT - 3/8

SN: P096338-UP

3шт.

|$21

26 317 R1

BOLT, HEX - 1/2NCx1-1/4

SN: P096338-UP

2шт.

|$22

25 555 R1

WASHER, FLAT - 1/2

SN: P096338-UP

2шт.

8

DOOR, R.H. SIDE (SEE FIG. M2140-03A0)

SN: P096338-UP

1шт.

|$24

26 310 R1

BOLT, HEX - 3/8NCx1

SN: P096338-UP

3шт.

|$25

25 553 R1

WASHER, FLAT - 3/8

SN: P096338-UP

3шт.

|$26

26 317 R1

BOLT, HEX - 1/2NCx1-1/4

SN: P096338-UP

2шт.

|$27

25 555 R1

WASHER, FLAT - 1/2

SN: P096338-UP

2шт.

9

679 070 C1

INSULATOR, AIR STACK

SN: P096338-UP

1шт.

10

1312 926 H91

COVER, REAR

SN: P096338-UP

1шт.

|$30

24 861 R1

BOLT, HEX - 1/2NCx1-1/4

SN: P096338-UP

2шт.

|$31

25 546 R1

WASHER, FLAT - 1/2

SN: P096338-UP

2шт.

|$32

25 768 R1

BOLT, HEX - 3/8NCx5/8

SN: P096338-UP

2шт.

|$33

25 553 R1

WASHER, FLAT - 3/8

SN: P096338-UP

2шт.

11

1277 043 H1

COVER, ACCESS

SN: P096338-UP

1шт.

|$35

24 839 R1

BOLT, HEX - 3/8NCx3/4

SN: P096338-UP

1шт.

|$36

25 534 R1

WASHER, FLAT - 3/8

SN: P096338-UP

1шт.

|$37

126 032

NUT, WING - 3/8NC

SN: P096338-UP

1шт.

12

1281 995 H92

BRACKET, HOOD TIE DOWN

SN: P096338-UP

2шт.

|$39

25 483 R1

BOLT, HEX - 1/4NCx1

SN: P096338-UP

4шт.

|$40

25 542 R1

WASHER, FLAT - 1/4

SN: P096338-UP

4шт.

13

1281 994 H1

ROD, TIE DOWN

SN: P096338-UP

2шт.

|$42

25 543 R1

WASHER, FLAT - 5/16

SN: P096338-UP

4шт.

|$43

9413 952

NUT, LOCK - 5/16NC

SN: P096338-UP

2шт.

14

617 867 C1

BALL, COMPRESSION

SN: P096338-UP

2шт.

15

1312 916 H92

GRABHANDLE

SN: P096338-UP

2шт.

16

25 553 R1

BOLT, HEX - 3/8NCx1

SN: P096338-UP

4шт.

17

26 310 R1

WASHER, FLAT - 3/8

SN: P096338-UP

4шт.
