Запчасти Komatsu D39E-1A FIG. K-7A УПРАВЛ-Е КОРПУС И РУКОЯТЬ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1268 198 H91

EQUIPMENT CONTROLS

SN: P096338-UP

1шт.

1

1250 600 H91

BRACKET, CONTROL

SN: P096338-UP

1шт.

2

1250 601 H93

LEVER, CONTROL

SN: P096338-UP

1шт.

3

1268 056 H2

HANDLE, LEVER

SN: P096338-UP

1шт.

|$4

21 063 R1

NUT, JAM - 1/2NF

SN: P096338-UP

1шт.

|$5

1250 606 H91

BELLCRANK ASSEMBLY, LIFT

SN: P096338-UP

1шт.

4

NSS

BELLCRANK, LIFT

SN: P096338-UP

1шт.

5

173 892 C91

BEARING, SHAFT

SN: P096338-UP

4шт.

|$8

26 052 R1

PIN, SPRING - 3/16x1-1/2.

SN: P096338-UP

1шт.

6

109 454

FITTING, LUBE

SN: P096338-UP

1шт.

7

16 964 R91

FITTING, LUBE

SN: P096338-UP

2шт.

8

1268 172 H1

SHAFT, MOUNTING

SN: P096338-UP

2шт.

|$12

19 444 R1

PIN, SPRING - 5/32x1-3/8

SN: P096338-UP

2шт.

|$13

1283 175 H91

BEARING ASSEMBLY, ROD END

SN: P096338-UP

1шт.

9

1283 174 H1

BEARING, ROD END

SN: P096338-UP

1шт.

10

1283 173 H1

ROD, THREADED

SN: P096338-UP

1шт.

|$16

26 258 R1

BOLT, HEX - 1/4NFx1-1/4

SN: P096338-UP

1шт.

|$17

27 122 R1

NUT, LOCK - 1/4NF

SN: P096338-UP

1шт.

11

1268 599 H1

SPACER, MOUNTING

SN: P096338-UP

1шт.

12

1283 174 H1

BEARING, ROD END

SN: P096338-UP

1шт.

|$20

24 737 R1

PIN, SPRING - 1/16x3/8.

SN: P096338-UP

1шт.

13

1278 058 H1

PIN, MOUNTING

SN: P096338-UP

3шт.

|$22

25 532 R1

WASHER, FLAT - 1/4

SN: P096338-UP

6шт.

|$23

103 362

PIN, COTTER - 1/16x3/4

SN: P096338-UP

6шт.

|$24

1268 820 H91

BELLCRANK ASSEMBLY, LIFT AND TILT

SN: P096338-UP

1шт.

14

NSS

BELLCRANK, LIFT AND TILT

SN: P096338-UP

1шт.

15

173 892 C91

BEARING, BELLCRANK

SN: P096338-UP

2шт.

16

1268 173 H1

SHAFT, CONTROL

SN: P096338-UP

1шт.

|$28

19 444 R1

PIN, SPRING - 5/32x1-3/8

SN: P096338-UP

1шт.

|$29

1268 821 H91

BELLCRANK ASSEMBLY, TILT

SN: P096338-UP

1шт.

17

NSS

BELLCRANK, TILT

SN: P096338-UP

1шт.

18

173 892 C91

BEARING, BELLCRANK

SN: P096338-UP

2шт.

19

16 964 R1

FITTING, LUBE 90 DEG

SN: P096338-UP

1шт.

20

1268 171 H1

SHAFT, CONTROL

SN: P096338-UP

1шт.

|$34

19 444 R1

PIN, SPRING - 5/32x1-3/8

SN: P096338-UP

1шт.

21

1267 356 H1

LINK, CONNECTING

SN: P096338-UP

1шт.

22

1267 356 H1

LINK, CONNECTING

SN: P096338-UP

1шт.

23

1269 250 H1

LINK, CONNECTING

SN: P096338-UP

1шт.

24

1283 166 H1

PIN, MOUNTING

SN: P096338-UP

4шт.

|$39

25 533 R1

WASHER, FLAT - 5/16

SN: P096338-UP

8шт.

|$40

103 362

PIN, COTTER - 1/16x3/4

SN: P096338-UP

8шт.

25

1250 614 H1

ROD, THREADED

SN: P096338-UP

1шт.

|$42

25 931 R1

NUT, JAM - 5/16NF

SN: P096338-UP

2шт.

26

310 673 R91

JOINT, BALL

SN: P096338-UP

2шт.

|$44

27 036 R1

NUT, LOCK - 5/16NF

SN: P096338-UP

1шт.

|$45

1268 822 H91

BELLCRANK ASSEMBLY, ANGLE

SN: P096338-UP

1шт.

27

NSS

BELLCRANK, ANGLE

SN: P096338-UP

1шт.

28

173 892 C91

BEARING, BELLCRANK

SN: P096338-UP

2шт.

29

117 175

FITTING, LUBE 45 DEG

SN: P096338-UP

1шт.

|$49

-1шт.

|$50

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$51

-1шт.
