Запчасти Komatsu D39E-1A FIG. K-A ПАНЕЛЬ ПРИБОРОВ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1306 506 H91

PANEL AND GAUGES

SN: P096338-UP

1шт.

|$1

1306 507 H91

PANEL ASSEMBLY, INSTRUMENT

SN: P096338-UP

1шт.

1

1306 420 H91

PANEL, INSTRUMENT

SN: P096338-UP

1шт.

2

1306 422 H1

PRODUCT GRAPHIC, PANEL

SN: P096338-UP

1шт.

3

CLUSTER, GAUGE (SEE FIG. K2210-02A0)

SN: P096338-UP

1шт.

|$5

179 389

SCREW, MOUNTING - #10-24x3/4

SN: P096338-UP

4шт.

4

1220 651 H2

HOURMETER

SN: P096338-UP

1шт.

5

1308 180 H1

SWITCH, START

SN: P096338-UP

1шт.

|$8

1308 333 H1

KEY, START

SN: P096338-UP

1шт.

|$9

1308 915 H1

NUT, KEY SWITCH

SN: P096338-UP

1шт.

6

1306 621 H1

GAUGE, FUEL LEVEL

SN: P096338-UP

1шт.

7

606 298 C91

SWITCH, LIGHTING

SN: P096338-UP

1шт.

|$12

131 718

WASHER, LOCK - 7/16

SN: P096338-UP

1шт.

8

740 347 C1

KNOB, LIGHT SWITCH

SN: P096338-UP

1шт.

9

1270 235 H91

LAMP, ILLUMINATION

SN: P096338-UP

1шт.

|$16

OR

-1шт.

|$18

1283 725 H91

LAMP, ILLUMINATION

SN: P096338-UP

1шт.

|$19

934 946 R1

WASHER, LOCK - M4.

SN: P096338-UP

2шт.

10

1134 719 C1

BREAKER, CIRCUIT - 20 AMP

SN: P096338-UP

2шт.

|$21

159 339

SCREW, MOUNTING - #6-32x1/2

SN: P096338-UP

4шт.

|$22

116 117

WASHER, LOCK - #6

SN: P096338-UP

4шт.

|$23

115 997

NUT, HEX - #6-32

SN: P096338-UP

4шт.

|$24

106 497

WASHER, LOCK - #10 (TERMINAL)

SN: P096338-UP

4шт.

|$25

120 614

NUT, HEX - #10-32 (TERMINAL)

SN: P096338-UP

4шт.

11

1432 615 H1

BREAKER, CIRCUIT - 6 AMP

SN: P096338-UP

1шт.

|$27

159 339

SCREW, MOUNTING - #6-32x1/2

SN: P096338-UP

2шт.

|$28

116 117

WASHER, LOCK - #6

SN: P096338-UP

2шт.

|$29

115 997

NUT, HEX - #6-32

SN: P096338-UP

2шт.

|$30

106 497

WASHER, LOCK - #10 (TERMINAL)

SN: P096338-UP

2шт.

|$31

120 614

NUT, HEX - #10-32 (TERMINAL)

SN: P096338-UP

2шт.

12

1306 803 H91

HARNESS, INSTRUMENT PANEL

SN: P096338-UP

1шт.

13

1249 210 H1

WIRE, JUMPER

SN: P096338-UP

2шт.

14

702 439 C1

MOUNT, RUBBER

SN: P096338-UP

4шт.

|$35

178 521

WASHER, LOCK - 1/4

SN: P096338-UP

12шт.

|$36

25 519 R1

NUT, HEX - 1/4NC

SN: P096338-UP

4шт.

|$37

131 593

NUT, HIGH CROWN - 1/4NC

SN: P096338-UP

4шт.

15

1128 402 C1

RECTIFIER DIODE

SN: P096338-UP

1шт.

|$39

23 979 R1

SCREW, MOUNTING - #8-18x1/2

SN: P096338-UP

2шт.

|$40

131 015

WASHER, FLAT - #8

SN: P096338-UP

2шт.

16

20 274 R1

BULB, LAMP - #356

SN: P096338-UP

1шт.

17

453 453 C1

SWITCH, ETHER START

SN: P096338-UP

1шт.

|$43

-1шт.

|$44

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$45

-1шт.

|$46

-1шт.

|$47

F2 - USED WITH ILLUMINATION LAMP 1283 725 H91 ONLY.

-1шт.

|$48

-1шт.
