Запчасти Komatsu D39E-1A FIG. K-A HEADLINER, КРЫЛОS, SWEEPS И ЗАДН. ЭКРАН - С СИСТЕМОЙ ROPS КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1312 963 H91

ROPS CANOPY WITH LINER, MIRROR

SN: P096338-UP

1шт.

1

1312 843 H1

MOUNT, BONDED

SN: P096338-UP

8шт.

|$2

1312 861 H1

WASHER, SPACER

SN: P096338-UP

4шт.

|$3

1312 862 H1

WASHER, SPACER

SN: P096338-UP

4шт.

|$4

25 996 R1

BOLT, HEX - 1 NCx6

SN: P096338-UP

4шт.

|$5

25 550 R1

WASHER, FLAT - 1

SN: P096338-UP

4шт.

|$6

9413 986

NUT, LOCK - 1 NC

SN: P096338-UP

4шт.

2

NSS

PLATE, SERIAL NUMBER

SN: P096338-UP

1шт.

|$8

145 373

SCREW, MOUNTING - #6x1/4

SN: P096338-UP

4шт.

3

ROPS CAUTION (SEE FIG. U0100-01A1)

SN: P096338-UP

1шт.

|$10

BELT, SEAT (SEE FIG. K0110-01A0)

SN: P096338-UP

1шт.

4

1312 819 H91

FRAME, ROPS

SN: P096338-UP

1шт.

5

1312 881 H91

HEADLINER, FOAM

SN: P096338-UP

1шт.

6

1284 629 H1

CLIP, MOUNTING

SN: P096338-UP

16шт.

7

1171 438 C1

BRACKET, MIRROR MOUNTING

SN: P096338-UP

1шт.

|$15

931 830 R1

BOLT, HEX - M8x20

SN: P096338-UP

2шт.

|$16

25 533 R1

WASHER, FLAT - 5/16

SN: P096338-UP

2шт.

8

1171 831 C1

MIRROR

SN: P096338-UP

1шт.

|$18

465 567 R1

BOLT, HEX - 1/2 NCx1-1/2

SN: P096338-UP

2шт.

|$19

25 546 R1

WASHER, FLAT - 1/2

SN: P096338-UP

2шт.

|$20

9412 230

NUT, LOCK - 1/2

SN: P096338-UP

2шт.

9

142 075

PLUG

SN: P096338-UP

1шт.

|$22

1300 486 H91

FENDERS AND PLATFORMS

SN: P096338-UP

1шт.

|$23

1300 612 H91

PLATE ASSEMBLY, FLOOR

SN: P096338-UP

1шт.

10

1300 613 H91

PLATE, FLOOR

SN: P096338-UP

1шт.

|$25

24 840 R1

BOLT, HEX - 3/8 NCx1

SN: P096338-UP

4шт.

|$26

25 553 R1

WASHER, FLAT - 3/8

SN: P096338-UP

4шт.

11

1299 607 H91

FENDER, LEFT

SN: P096338-UP

1шт.

|$28

24 891 R1

BOLT, HEX - 3/4 NCx2-3/4

SN: P096338-UP

4шт.

|$29

25 548 R1

WASHER, FLAT - 3/4

SN: P096338-UP

4шт.

12

1299 608 H91

FENDER, RIGHT

SN: P096338-UP

1шт.

|$31

24 891 R1

BOLT, HEX - 3/4 NCx2-3/4

SN: P096338-UP

4шт.

|$32

25 548 R1

WASHER, FLAT - 3/4

SN: P096338-UP

4шт.

|$33

1312 964 H91

FRONT SWEEPS

SN: P096338-UP

1шт.

13

153 343 H1

BUSHING, ISO MOUNT

SN: P096338-UP

4шт.

|$35

25 680 R1

BOLT, HEX - 5/8 NCx6

SN: P096338-UP

2шт.

|$36

M 22 352

WASHER, FLAT - 21/32

SN: P096338-UP

4шт.

|$37

9412 231

NUT, LOCK - 5/8 NC

SN: P096338-UP

2шт.

14

1259 993 H1

LUG, MOUNTING

SN: P096338-UP

2шт.

15

1308 061 H1

CROSSMEMBER

SN: P096338-UP

1шт.

|$40

24 876 R1

BOLT, HEX - 5/8 NCx2-1/4

SN: P096338-UP

2шт.

|$41

25 537 R1

WASHER, FLAT - 5/8

SN: P096338-UP

4шт.

|$42

9412 231

NUT, LOCK - 5/8 NC

SN: P096338-UP

2шт.

16

1312 890 H91

SWEEP, LEFT

SN: P096338-UP

1шт.

|$44

24 882 R1

BOLT, HEX - 5/8 NCx4-1/2

SN: P096338-UP

1шт.

|$45

25 556 R1

WASHER, FLAT - 5/8

SN: P096338-UP

1шт.

17

1312 892 H91

SWEEP, RIGHT

SN: P096338-UP

1шт.

|$47

24 882 R1

BOLT, HEX - 5/8 NCx4-1/2

SN: P096338-UP

1шт.

|$48

25 556 R1

WASHER, FLAT - 5/8

SN: P096338-UP

1шт.

|$49

1312 989 H91

SCREEN, CANOPY REAR

SN: P096338-UP

1шт.

18

1312 888 H91

SCREEN ASSY, REAR

SN: P096338-UP

1шт.

|$51

-1шт.

|$52

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$53

-1шт.
