Запчасти Komatsu D39E-1A FIG. K-A КАБИНА И АКСЕССУАРЫ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1309 714 H91

CAB AND ACCESSORIES

SN: P096338-UP

1шт.

1

1304 392 H1

INSULATION, REAR

SN: P096338-UP

1шт.

2

1300 559 H1

UNDERLAYMENT, FLOOR

SN: P096338-UP

1шт.

3

1304 439 H1

FLOORMAT, FLOOR

SN: P096338-UP

1шт.

4

1304 440 H1

FLOORMAT, FIREWALL

SN: P096338-UP

1шт.

|$5

31 006 R1

SCREW, PAN HEAD - M6x16

SN: P096338-UP

2шт.

|$6

1309 381 H1

WASHER, FLAT

SN: P096338-UP

2шт.

|$7

1304 446 H91

DASH COWL GUARD ASSEMBLY

SN: P096338-UP

1шт.

5

NSS

WELDMENT, DASH

SN: P096338-UP

1шт.

6

1299 714 H2

SEAL, TOP

SN: P096338-UP

1шт.

7

1299 716 H1

SEAL, BOTTOM

SN: P096338-UP

2шт.

8

TRIM, EDGE - 3.8 FT.

SN: P096338-UP

1шт.

|$12

24 840 R1

BOLT, HEX HEAD - 3/8NCX1

SN: P096338-UP

8шт.

|$13

25 534 R1

WASHER, FLAT - 3/8

SN: P096338-UP

8шт.

9

1300 638 H1

PLATE, PIN

SN: P096338-UP

1шт.

|$15

1309 447 H1

PIN, GROOVE

SN: P096338-UP

4шт.

10

1304 407 H91

GUARD, OUTER

SN: P096338-UP

1шт.

|$17

24 840 R1

BOLT, HEX HEAD - 3/8NCX1

SN: P096338-UP

4шт.

|$18

25 534 R1

WASHER, FLAT - 3/8

SN: P096338-UP

4шт.

11

1309 363 H1

ANGLE, DASH

SN: P096338-UP

1шт.

|$20

31 006 R1

SCREW, PAN HEAD - M6x16

SN: P096338-UP

2шт.

|$21

1309 381 H1

WASHER, FLAT

SN: P096338-UP

2шт.

12

1304 189 H2

GASKET, RIGHT

SN: P096338-UP

1шт.

13

1304 190 H2

GASKET, LEFT

SN: P096338-UP

1шт.

14

1171 831 C1

MIRROR, REAR VIEW

SN: P096338-UP

1шт.

|$25

465 567 R1

BOLT, CARRIAGE - 1/2NCx1-1/2

SN: P096338-UP

2шт.

|$26

25 546 R1

WASHER, FLAT - 1/2

SN: P096338-UP

2шт.

|$27

9412 230

NUT, LOCK - 1/2NC

SN: P096338-UP

2шт.

15

1309 251 H1

CHANNEL, MIRROR

SN: P096338-UP

1шт.

|$29

30 002 R1

BOLT, HEX HEAD - M8x20

SN: P096338-UP

2шт.

|$30

25 533 R1

WASHER, FLAT - 5/16

SN: P096338-UP

2шт.

16

CASE, MANUAL (SEE FIG. K0210-02A0)

SN: P096338-UP

1шт.

17

1304 110 H91

BRACKET, RIGHT MOUNTING

SN: P096338-UP

1шт.

|$33

1300 616 H1

BLOCK, RETAINER STOP

SN: P096338-UP

1шт.

18

1304 111 H91

BRACKET, LEFT MOUNTING

SN: P096338-UP

1шт.

19

195-978-1311

ISOLATOR, MOUNTING

SN: P096338-UP

4шт.

|$36

25 996 R1

BOLT, HEX HEAD - 1NCx6

SN: P096338-UP

4шт.

|$37

25 550 R1

WASHER, FLAT - 1

SN: P096338-UP

4шт.

|$38

9413 986

NUT, LOCK - 1NC

SN: P096338-UP

3шт.

|$39

1300 600 H1

BLOCK, THREADED

SN: P096338-UP

1шт.

20

1287 385 H1

SLEEVE, EXTRUDED

SN: P096338-UP

2шт.

21

610 395 R1

SPACER, PIPE

SN: P096338-UP

4шт.

22

636 888 C3

BELT, SEAT

SN: P096338-UP

1шт.

|$43

24 864 R1

BOLT, MOUNTING - 1/2NCx2

SN: P096338-UP

2шт.

|$44

25 555 R1

WASHER, FLAT - 1/2

SN: P096338-UP

4шт.

|$45

9412 230

NUT, LOCK - 1/2NC

SN: P096338-UP

2шт.

23

CAB, ROPS (SEE FIG. K0210-03A0)

SN: P096338-UP

1шт.

24

HEATER, CAB (SEE FIG. K0710-01A0)

SN: P096338-UP

1шт.

|$48

1262 660 H1

TRIM, BULK EDGE

SN: P096338-UP

-2шт.

|$49

-1шт.

|$50

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$51

-1шт.

|$52

-1шт.

|$53

F2 - CUT REQUIRED LENGTH FROM BULK EDGE TRIM 1262 660 H1.

-1шт.

|$54

-1шт.

|$55

-1шт.

|$56

F3 - USE FOR SEAT WITHOUT SEAT BELT RETRACTOR.

-1шт.

|$57

-1шт.
