Запчасти Komatsu D39E-1A FIG. K-A СИДЕНЬЕ КРЕПЛЕНИЕ - БЕЗ РЕМЕНЬ БЕЗОПАСНОСТИ RETRACTOR - КАБИНА ROPS КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

SEAT, SUSPENSION (SEE FIG. K0110-02A0)

SN: P096338-UP

1шт.

|$1

25 552 R1

WASHER, FLAT - 5/16

SN: P096338-UP

4шт.

|$2

25 520 R1

NUT, HEX - 5/16NC

SN: P096338-UP

4шт.

2

1309 250 H92

ARM REST

SN: P096338-UP

2шт.

|$4

24 839 R1

BOLT, HEX - 3/8NCx3/4

SN: P096338-UP

4шт.

|$5

25 534 R1

WASHER, FLAT - 3/8

SN: P096338-UP

4шт.

3

1309 249 H1

BRACKET, MOUNTING

SN: P096338-UP

2шт.

|$7

24 839 R1

BOLT, HEX - 3/8NCx3/4

SN: P096338-UP

4шт.

|$8

25 534 R1

WASHER, FLAT - 3/8

SN: P096338-UP

4шт.

4

1304 125 H91

PLATE ASSEMBLY (SEAT MOUNTING)

SN: P096338-UP

1шт.

|$10

SHIM (SEE FIG. D0100-01A0)

SN: P096338-UP

-2шт.

|$11

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P096338-UP

6шт.

|$12

25 553 R1

WASHER, FLAT - 3/8

SN: P096338-UP

6шт.

|$13

24 860 R1

BOLT, HEX - 1/2NCx1

SN: P096338-UP

3шт.

|$14

25 555 R1

WASHER, FLAT - 1/2

SN: P096338-UP

3шт.

5

CHANNEL ASSEMBLY (SEE FIG. K0710-01A0)

SN: P096338-UP

1шт.

|$16

24 848 R1

BOLT, HEX - 7/16NCx3/4

SN: P096338-UP

4шт.

|$17

25 553 R1

WASHER, FLAT - 3/8

SN: P096338-UP

4шт.

6

3071 294 R1

BOSS, MOUNTING - TUBE CLAMP

SN: P096338-UP

1шт.

7

1300 689 H1

BAR, SEAT MOUNTING

SN: P096338-UP

2шт.

|$20

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P096338-UP

4шт.

|$21

25 553 R1

WASHER, FLAT - 3/8

SN: P096338-UP

4шт.

8

636 888 C3

BELT, SEAT

SN: P096338-UP

1шт.

|$23

24 864 R1

BOLT, HEX - 1/2NCx2

SN: P096338-UP

2шт.

|$24

25 555 R1

WASHER, FLAT - 1/2

SN: P096338-UP

4шт.

|$25

9412 230

NUT, LOCK - 1/2NC

SN: P096338-UP

2шт.

9

1287 385 H1

SLEEVE, EXTRUDED

SN: P096338-UP

2шт.

10

610 395 R1

SPACER, PIPE

SN: P096338-UP

4шт.

|$28

-1шт.

|$29

F1 - USE SHIMS AS REQUIRED TO ELIMINATE GAPS BETWEEN THE LIP OF THE PLATE ASSEMBLY (SEAT MOUNTING) AND THE FUEL TANK.

-1шт.

|$30

-1шт.
