Запчасти Komatsu D39E-1A FIG. J-A ЗАДН. ОСНОВН. РАМА ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

|$0

706 173 C92

FRAME ASSEMBLY, REAR MAIN

SN: P096338-UP

1шт.

1

NSS

FRAME

SN: P096338-UP

1шт.

2

621 546 C1

DOWEL, SHOE

SN: P096338-UP

8шт.

3

621 547 C1

DOWEL, FINAL DRIVE

SN: P096338-UP

4шт.

4

621 090 C91

BEARING, NEEDLE

SN: P096338-UP

4шт.

5

613 908 C1

PLUG, PIPE

SN: P096338-UP

4шт.

6

271 647 R1

PLUG, DRAIN

SN: P096338-UP

1шт.

7

601 093 C1

PLUG, CUP

SN: P096338-UP

2шт.

8

652 817 C1

TUBE, BRAKE ROD

SN: P096338-UP

1шт.

9

621 549 C1

INSERT, ADJUSTING BOLT

SN: P096338-UP

2шт.

10

104 942

PLUG, CORK #6

SN: P096338-UP

-2шт.

11

117 926

PLUG, CORK #12

SN: P096338-UP

-2шт.

12

23 624 R1

PLUG, CUP

SN: P096338-UP

4шт.

|$13

-1шт.

|$14

F1 - SERVICE PART WILL BE AVAILABLE ON SPECIAL ORDER WITH THE CLEARANCE OF THE ENGINEERING DEPARTMENT. PRODUCT IDENTIFICATION NUMBER (PIN) MUST BE FURNISHED WHEN ORDERING. ORDER ON MACHINE ORDER FORM.

-1шт.

|$15

-1шт.
