Запчасти Komatsu D39E-1A FIG. H-A ГИДРОЛИНИЯ - ПЕРЕКОС. ОТВАЛА ГИДРАВЛИКА

1

VALVE, 3-SPOOL (SEE FIG. H0120-01A0)

SN: P096338--UP

1шт.

|$2

OR

-1шт.

|$4

VALVE, 4-SPOOL (SEE FIG. H0120-02A0)

SN: P096338--UP

1шт.

2

9410 204

CONNECTOR

SN: P096338--UP

2шт.

|$6

364 885 R1

RING, SEAL

SN: P096338--UP

2шт.

|$7

1285 291 H1

VENT, ORIFICE - 0.125 INTOP AND BOTTOM PORT

SN: P096338--UP

2шт.

3

1271 304 H1

TUBE, HEAD TILT

SN: P096338--UP

1шт.

4

1271 305 H1

TUBE, ROD TILT

SN: P096338--UP

1шт.

5

BRACKET (SEE FIG. H2210-01A0)

SN: P096338--UP

1шт.

6

653 171 C1

CLAMP, TILT HOSE

SN: P096338--UP

1шт.

|$12

24 842 R1

BOLT, HEX - 3/8NCx1-3/4

SN: P096338--UP

1шт.

|$13

25 553 R1

WASHER, FLAT - 3/8

SN: P096338--UP

1шт.

|$14

25 522 R1

NUT, HEX - 3/8NC

SN: P096338--UP

1шт.

|$15

26 241 H

SPACER, CLAMP

SN: P096338--UP

1шт.

7

134 794 H1

HOSE, HEAD TILT

SN: P096338--UP

1шт.

8

1271 356 H1

HOSE, ROD TILT

SN: P096338--UP

1шт.

9

9410 203

CONNECTOR

SN: P096338--UP

4шт.

|$19

570 828 R1

RING, SEAL

SN: P096338--UP

4шт.

10

1277 025 H1

HOSE, TILT

SN: P096338--UP

2шт.

11

1271 366 H91

TUBE, R.H. TILT

SN: P096338--UP

1шт.

|$22

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P096338--UP

1шт.

|$23

25 553 R1

WASHER, FLAT - 3/8

SN: P096338--UP

1шт.

12

1271 365 H91

TUBE, L.H. TILT

SN: P096338--UP

1шт.

|$25

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P096338--UP

1шт.

|$26

25 553 R1

WASHER, FLAT - 3/8

SN: P096338--UP

1шт.

13

308 575 C1

CLIP, TUBE

SN: P096338--UP

6шт.

|$28

24 839 R1

BOLT, HEX - 3/8NCx3/4

SN: P096338--UP

6шт.

|$29

25 534 R1

WASHER, FLAT - 3/8

SN: P096338--UP

6шт.

14

1286 694 H91

GUARD, TILT TUBE

SN: P096338--UP

2шт.

|$31

24 843 R1

BOLT, HEX - 3/8NCx2

SN: P096338--UP

4шт.

|$32

25 534 R1

WASHER, FLAT - 3/8

SN: P096338--UP

4шт.

15

308 575 C1

CLIP, TILT HOSE

SN: P096338--UP

4шт.

16

1213 957 H2

HOSE, CYLINDER

SN: P096338--UP

2шт.

17

9410 978

ELBOW, 90-DEGREE

SN: P096338--UP

2шт.

|$36

364 885 R1

RING, SEAL

SN: P096338--UP

2шт.

18

CYLINDER, TILT (SEE FIG. T2180-01A0)

SN: P096338--UP

1шт.

19

1277 747 H1

CLAMP, THREE-HOSE

SN: P096338--UP

4шт.

|$39

25 285 R1

BOLT 1/2-13X3 1/4

SN: P096338--UP

4шт.

|$40

25 536 R1

WASHER 1/2-A

SN: P096338--UP

4шт.

|$41

116 121

WASHER, LOCK

SN: P096338--UP

4шт.

|$42

306 132 C2

STRAP, TIE

SN: P096338--UP

-2шт.
