Запчасти Komatsu D39E-1A FIG. H-A ОТВАЛ ANGLE ИЛИ РЫХЛИТЕЛЬ SECTION ГИДРАВЛИКА

|$0

1299 225 H92

SECTION ASSEMBLY, BLADE ANGLE OR RIPPER

SN: P096338-UP

1шт.

1

POSITIONER (SEE FIG. H0120-08A0)

SN: P096338-UP

1шт.

2

VALVE, ANTI CAVITATION (SEE FIG. H0120-10A0)

2шт.

|$4

1299 238 H91

SEAL ASSEMBLY, SPOOL

SN: P096338-UP

2шт.

3

850 880 C1

RETAINER, SEAL

SN: P096338-UP

1шт.

|$6

1299 239 H1

KIT, SEAL

SN: P096338-UP

1шт.

4

NSS

RING, BACK UP

SN: P096338-UP

1шт.

5

NSS

RING, SEAL

SN: P096338-UP

1шт.

|$9

1299 240 H1

KIT, SEAL PLATE

SN: P096338-UP

1шт.

6

NSS

PLATE, SEAL

SN: P096338-UP

1шт.

|$11

NSS

BOLT, HEX - 1/4NCx1/2

SN: P096338-UP

2шт.

7

NSS

SPOOL, SECTION

SN: P096338-UP

1шт.

8

NSS

HOUSING, SECTION

SN: P096338-UP

1шт.

|$14

-1шт.

|$15

F2 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$16

-1шт.

|$17

-1шт.

|$18

F2 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$19

-1шт.

|$20

-1шт.

|$21

F3 - FORM SHIPPING PURPOSES ONLY. USE FOR SERVICING SECTION.

-1шт.

|$22

-1шт.
