Запчасти Komatsu D39E-1A FIG. H-A THREE СЕКЦ. УПРАВЛЯЮЩ. КЛАПАН ГИДРАВЛИКА

|$0

1259 210 H92

VALVE ASSEMBLY, THREE SPOOL CONTROL

SN: P096338-UP

1шт.

|$1

1299 222 H91

COVER ASSEMBLY, INLET

SN: P096338-UP

1шт.

1

NSS

COVER, INLET

SN: P096338-UP

1шт.

2

VALVE, RELIEF (SEE FIG. H0120-03A0)

SN: P096338-UP

1шт.

3

9410 361

PLUG, PORT

SN: P096338-UP

1шт.

|$5

368 269 R1

RING, SEAL

SN: P096338-UP

1шт.

4

BLADE LIFT (SEE FIG. H0120-04A0)

SN: P096338-UP

1шт.

5

BLADE TILT (SEE FIG. H0120-05A0)

SN: P096338-UP

1шт.

6

BLADE ANGLE (SEE FIG. H0120-06A0)

SN: P096338-UP

1шт.

|$9

1299 226 H91

COVER ASSEMBLY, OUTLET

SN: P096338-UP

1шт.

7

NSS

COVER, OUTLET

SN: P096338-UP

1шт.

8

9410 362

PLUG, PORT

SN: P096338-UP

1шт.

|$12

297 459 R1

RING, SEAL

SN: P096338-UP

1шт.

|$13

1299 227 H1

KIT, BETWEEN SECTION

SN: P096338-UP

4шт.

9

NSS

RING, SEAL

SN: P096338-UP

2шт.

10

NSS

RING, SEAL

SN: P096338-UP

2шт.

|$16

1299 228 H1

KIT, STUD

SN: P096338-UP

1шт.

11

NSS

BOLT, HEX

SN: P096338-UP

3шт.

12

NSS

NUT, HEX

SN: P096338-UP

3шт.

|$19

-1шт.

|$20

F1 - THE SEAL KIT CONTAINS ONE EXTRA SET OF SEAL RINGS.

-1шт.

|$21

-1шт.
