Запчасти Komatsu D39E-1A FIG. H-A ГИДРАВЛ МАСЛ. РЕЗЕРВУАР - С СИСТЕМОЙ ROPS ГИДРАВЛИКА

|$0

1306 144 H92

RESERVOIR AND FILTER

SN: P096338-UP

1шт.

1

1306 145 H92

RESERVOIR

SN: P096338-UP

1шт.

2

1300 743 H91

COVER

SN: P096338-UP

1шт.

|$3

24 839 R1

BOLT, HEX - 3/8NCx3/4

SN: P096338-UP

4шт.

|$4

25 534 R1

WASHER, FLAT - 3/8

SN: P096338-UP

4шт.

|$5

1300 752 H91

DOOR ASSEMBLY, RESERVOIR

SN: P096338-UP

1шт.

3

NSS

DOOR, ACCESS

SN: P096338-UP

1шт.

4

1297 517 H91

LATCH, DOOR

SN: P096338-UP

1шт.

|$8

104 067

RIVET, BUTTON HEAD - 3/16x1/2

SN: P096338-UP

4шт.

|$9

650 382 C92

PADLOCK WITH KEYS

SN: P096338-UP

1шт.

|$10

1311 216 H1

KEY, REPLACEMENT

SN: P096338-UP

1шт.

5

1300 753 H91

HINGE, DOOR

SN: P096338-UP

1шт.

|$12

21 335 R1

BOLT, HEX - 3/8NCx3/4

SN: P096338-UP

3шт.

|$13

390 305 C1

WASHER, FLAT - 3/8

SN: P096338-UP

3шт.

|$14

24 838 R1

BOLT, HEX - 3/8NCx1/2

SN: P096338-UP

3шт.

|$15

390 305 C1

WASHER, FLAT - 3/8

SN: P096338-UP

3шт.

6

1300 708 H91

STRIKER, DOOR

SN: P096338-UP

1шт.

|$17

25 523 R1

NUT, HEX - 3/8NC

SN: P096338-UP

2шт.

|$18

390 305 C1

WASHER, FLAT - 3/8

SN: P096338-UP

2шт.

7

1299 593 H91

HANDLE, GRAB

SN: P096338-UP

1шт.

|$20

24 839 R1

BOLT, HEX - 3/8NCx3/4

SN: P096338-UP

2шт.

|$21

25 534 R1

WASHER, FLAT - 3/8

SN: P096338-UP

2шт.

8

1308 809 H1

LINK

SN: P096338-UP

1шт.

|$23

20 791 R1

PIN, CLEVIS - 1/4x29/32

SN: P096338-UP

1шт.

|$24

22 256 R1

WASHER, FLAT - 9/32

SN: P096338-UP

1шт.

|$25

103 361

PIN, COTTER - 1/16x1/2

SN: P096338-UP

1шт.

9

1302 398 H1

SPRING

SN: P096338-UP

1шт.

|$27

23 840 R1

PIN, CLEVIS - 5/16x1-3/16

SN: P096338-UP

1шт.

|$28

120 393

WASHER, FLAT - 5/16

SN: P096338-UP

2шт.

|$29

119 117

PIN, COTTER - 3/32x1/2

SN: P096338-UP

1шт.

10

294 118 R2

PLUG, FILL

SN: P096338-UP

1шт.

|$31

253 172 R1

0-RING

SN: P096338-UP

1шт.

11

9410 361

PLUG, DRAIN

SN: P096338-UP

1шт.

|$33

368 269 R1

RING, SEAL

SN: P096338-UP

1шт.

12

1214 473 H91

VALVE ASSEMBLY, VACUUM/PRESSURE RELIEF

SN: P096338-UP

1шт.

|$35

883 170 C91

KIT, VALVE REPAIR

SN: P096338-UP

1шт.

|$36

NSS

FILTER

SN: P096338-UP

1шт.

|$37

NSS

RING, SEAL

SN: P096338-UP

2шт.

13

933 022 C1

GAUGE, SIGHT

SN: P096338-UP

1шт.

|$39

364 145 R1

RING, SEAL

SN: P096338-UP

1шт.

14

1269 422 H1

STRAINER, SUCTION

SN: P096338-UP

1шт.

|$41

307 916 R1

RING, SEAL

SN: P096338-UP

1шт.

15

FILTER (SEE FIG. H0210-02A0)

SN: P096338-UP

1шт.

|$43

24 839 R1

BOLT, HEX - 3/8NCx3/4

SN: P096338-UP

2шт.

|$44

25 553 R1

WASHER, FLAT - 3/8

SN: P096338-UP

2шт.

16

1269 409 H1

ADAPTER, FILTER

SN: P096338-UP

1шт.

|$46

296 247 R1

RING, SEAL

SN: P096338-UP

1шт.

17

9410 981

ELBOW, 90 DEG

SN: P096338-UP

1шт.

|$48

296 247 R1

RING, SEAL

SN: P096338-UP

1шт.

18

1306 539 H1

SEAL

SN: P096338-UP

2шт.

19

1308 472 H1

PLATE, COVER

SN: P096338-UP

1шт.

|$51

145 384

SCREW, MOUNTING - #7 DRIVE

SN: P096338-UP

4шт.

|$52

24 875 R1

BOLT, HEX - 5/8NCx2

SN: P096338-UP

4шт.

|$53

25 547 R1

WASHER, FLAT - 5/8

SN: P096338-UP

4шт.

20

1306 183 H91

PLATE, COVER

SN: P096338-UP

1шт.

|$55

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P096338-UP

5шт.

|$56

25 553 R1

WASHER, FLAT - 3/8

SN: P096338-UP

5шт.

21

1299 603 H1

SHIM, MOUNTING

SN: P096338-UP

-2шт.

22

1304 257 H91

BRACKET, MOUNTING

SN: P096338-UP

1шт.

|$59

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P096338-UP

2шт.

|$60

25 553 R1

WASHER, FLAT - 3/8

SN: P096338-UP

2шт.

23

1304 245 H91

GUARD, LOWER

SN: P096338-UP

1шт.

|$62

24 840 R1

BOLT, HEX - 3/8NCx1

SN: P096338-UP

2шт.

|$63

25 544 R1

WASHER, FLAT - 3/8

SN: P096338-UP

2шт.

24

1312 935 H91

CONVENIENCE PACKAGE

SN: P096338-UP

1шт.

|$65

419 926 A190

CUP HOLDER

SN: P096338-UP

1шт.

|$66

23 979 R1

SCREW

SN: P096338-UP

4шт.

|$67

-1шт.

|$68

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$69

-1шт.
