Артикул
Название
Примечание
Количество
|$0
635 988 C94
TRANSMISSION WITH VALVES
SN: P096338-UP
1шт.
1
HOUSING AND INTERNAL PARTS(SEE FIG. F2320-52A1)
1шт.
2
716 912 C2
GASKET, MANIFOLD
SN: P096338-UP
1шт.
3
716 911 C1
MANIFOLD, VALVE
SN: P096338-UP
1шт.
|$5
24 843 R1
BOLT, HEX 3/8NCx2
SN: P096338-UP
3шт.
|$6
24 841 R1
BOLT, HEX 3/8NCx11/2
SN: P096338-UP
8шт.
|$7
25 534 R1
WASHER, FLAT 3/8
SN: P096338-UP
11шт.
4
738 058 C1
STRAINER, ORIFICE
SN: P096338-UP
1шт.
|$10
OR
-1шт.
|$12
738 444 C1
STRAINER, ORIFICE
SN: P096338-UP
1шт.
5
VALVE, PRESSURE REGULATOR (SEE FIG. F2320-52A6)
1шт.
|$15
24 845 R1
BOLT, HEX 3/8NCx4
SN: P096338-UP
3шт.
|$16
25 534 R1
WASHER, FLAT 3/8
SN: P096338-UP
3шт.
|$17
372 821 R1
RING, SEAL - LARGE
SN: P096338-UP
2шт.
|$18
252 707 R1
RING, SEAL - SMALL
SN: P096338-UP
2шт.
6
VALVE, RANGE SELECTOR (SEE FIG. F2320-52A7)
1шт.
|$21
25 501 R1
BOLT, HEX 3/8NCx33/4
SN: P096338-UP
3шт.
|$22
25 534 R1
WASHER, FLAT 3/8
SN: P096338-UP
3шт.
|$23
252 707 R1
RING, SEAL
SN: P096338-UP
10шт.
7
VALVE, RATE OF RISE (SEE FIG. F2320-52A8)
1шт.
|$26
25 501 R1
BOLT, HEX 3/8NCx33/4
SN: P096338-UP
3шт.
|$27
275 804 R1
BOLT, HEX 3/8NCx3
SN: P096338-UP
1шт.
|$28
25 534 R1
WASHER, FLAT 3/8
SN: P096338-UP
4шт.
8
657 951 C3
GASKET, VALVE
SN: P096338-UP
1шт.
9
709 590 C1
TUBE, SCAVENGE
SN: P096338-UP
1шт.
10
734 040 C2
GASKET, SCAVENGE TUBE
SN: P096338-UP
1шт.
11
9410 358
PLUG, PORT
SN: P096338-UP
1шт.
|$34
-1шт.
|$35
F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.
-1шт.
|$36
-1шт.
|$37
-1шт.
|$38
F2 - PART OF TRANSMISSION SERVICE KIT 741 453 C93.
-1шт.
|$39
-1шт.
Выбрано товаров: 34
