Запчасти Komatsu D39E-1A FIG. F-A ТРАНСМИССИЯ - COMPLETE ASSEMBLY СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

1306 666 H92

TRANSMISSION ASSEMBLY, COMPLETE

SN: P096338-UP

1шт.

1

TRANS, W/ VALVES (SEE FIG. F2320-52A0)

SN: P096338-UP

1шт.

2

1308 378 H1

ELBOW, REGULATOR, 90 DEG - M PORT

SN: P096338-UP

1шт.

|$3

296 247 R1

RING, SEAL

SN: P096338-UP

1шт.

3

380 633 R1

CONNECTOR - C PORT

SN: P096338-UP

1шт.

|$5

296 247 R1

RING, SEAL

SN: P096338-UP

1шт.

4

585 694 R1

ELBOW, 90 DEG

SN: P096338-UP

4шт.

5

667 958 C1

CONNECTOR - L PORT

SN: P096338-UP

1шт.

|$8

296 247 R1

RING, SEAL

SN: P096338-UP

1шт.

6

662 014 C1

HOSE, R OR 2ND

SN: P096338-UP

2шт.

7

336 081 R91

HOSE, F

SN: P096338-UP

1шт.

8

717 130 C1

HOSE, 1ST

SN: P096338-UP

1шт.

9

9411 107

ELBOW, 45 DEG

SN: P096338-UP

1шт.

|$13

368 269 R1

RING, SEAL

SN: P096338-UP

1шт.

10

444 613

PLUG, PIPE

SN: P096338-UP

1шт.

11

9402 708

CONNECTOR

SN: P096338-UP

1шт.

12

9410 254

ELBOW, 45 DEG

SN: P096338-UP

1шт.

13

9410 202

CONNECTOR - R PORT

SN: P096338-UP

1шт.

|$18

364 839 R1

RING, SEAL

SN: P096338-UP

1шт.

14

9411 104

ELBOW, 45 DEG - F AND 2 PORTS

SN: P096338-UP

2шт.

|$20

364 839 R1

RING, SEAL

SN: P096338-UP

2шт.

15

9410 976

ELBOW, 90 DEG - 1 PORT

SN: P096338-UP

1шт.

|$22

364 839 R1

RING, SEAL

SN: P096338-UP

1шт.

16

27 843 R1

CLAMP, HOSE

SN: P096338-UP

1шт.

17

SLEEVE, PROTECTIVE - 24IN LONG

SN: P096338-UP

1шт.

18

TEE, SUPPLY (SEE FIG. F2300-04A0)

SN: P096338-UP

1шт.

19

VALVE, TRANS/STRG(SEE FIG. F2300-09A0)

SN: P096338-UP

1шт.

|$27

160 927

SLEEVE, BULK PROTECTIVE

SN: P096338-UP

-2шт.

|$75

-1шт.

|$28

741 453 C93

KIT, TRANSMISSION SERVICE

SN: P096338-UP

1шт.

|$29

659 910 C1

SEAL PISTON

SN: P096338-UP

5шт.

|$30

659 913 C1

RING, SEAL

SN: P096338-UP

5шт.

|$31

709 631 C1

SEAL, PISTON

SN: P096338-UP

4шт.

|$32

709 632 C1

RING SEAL

SN: P096338-UP

4шт.

|$33

659 720 C1

SEAL, PISTON

SN: P096338-UP

1шт.

|$34

659 726 C1

RING, SEAL

SN: P096338-UP

1шт.

|$35

716 841 C1

RING, SEAL

SN: P096338-UP

4шт.

|$37

OR

-1шт.

|$39

327 090 R3

RING, SEAL

SN: P096338-UP

4шт.

|$40

22 410 R1

RING, SEAL, COUNTERSHAFT COVER

SN: P096338-UP

1шт.

|$41

716 840 C1

RING, SEAL

SN: P096338-UP

4шт.

|$43

OR

-1шт.

|$45

716 747 C1

RING, SEAL

SN: P096338-UP

4шт.

|$46

707 253 R1

RING, SEAL, REVERSE IDLER SHAFT

SN: P096338-UP

1шт.

|$47

21 924 R1

RING, SEAL, OUTPUT SHAFT

SN: P096338-UP

2шт.

|$48

301 016 R1

RING, SEAL, ADAPTER FITTING

SN: P096338-UP

1шт.

|$49

372 821 R1

RING, SEAL, REG VALVE LARGE

SN: P096338-UP

2шт.

|$50

252 707 R1

RING, SEAL, REG SMALL AND SELEC VLV

SN: P096338-UP

12шт.

|$51

364 839 R1

RING, SEAL, FITTING

SN: P096338-UP

7шт.

|$52

296 247 R1

RING, SEAL, FITTING

SN: P096338-UP

3шт.

|$53

368 269 R1

RING, SEAL, LUBE ELBOW

SN: P096338-UP

1шт.

|$54

936 658 C1

RING, SEAL, TRANSMISSION CASE

SN: P096338-UP

1шт.

|$55

705 495 C1

SHIM, INPUT AND COUNTERSHAFT - 0.005IN

SN: P096338-UP

8шт.

|$56

705 496 C1

SHIM, INPUT AND COUNTERSHAFT - 0.007IN

SN: P096338-UP

8шт.

|$57

705 497 C1

SHIM, INPUT AND COUNTERSHAFT - 0.030IN

SN: P096338-UP

8шт.

|$58

705 492 C1

SHIM, OUTPUT CLUTCH - 0.005IN

SN: P096338-UP

8шт.

|$59

705 493 C1

SHIM, OUTPUT CLUTCH - 0.007IN

SN: P096338-UP

8шт.

|$60

705 494 C1

SHIM, OUTPUT CLUTCH - 0.030IN

SN: P096338-UP

8шт.

|$61

259 246 R1

RING, SEAL, RANGE CLUTCH

SN: P096338-UP

1шт.

|$62

621 156 C1

SHIM, TRANS MOUNTING - 0.002IN

SN: P096338-UP

4шт.

|$63

621 157 C1

SHIM, TRANS MOUNTING - 0.007IN

SN: P096338-UP

4шт.

|$64

621 158 C1

SHIM, TRANS MOUNTING - 0.020IN

SN: P096338-UP

8шт.

|$65

716 912 C2

GASKET, MANIFOLD

SN: P096338-UP

1шт.

|$66

657 951 C3

GASKET, RATE OF RISE VALVE

SN: P096338-UP

1шт.

|$67

734 040 C2

GASKET, SCAVENGE TUBE

SN: P096338-UP

1шт.

|$68

666 154 C3

GASKET, PILOT VALVE

SN: P096338-UP

1шт.

|$69

-1шт.

|$70

F1 - PART OF TRANSMISSION SERVICE KIT 741 453 C93.

-1шт.

|$71

-1шт.

|$72

-1шт.

|$73

F2 - CUT REQUIRED LENGTH FROM BILK PROTECTIVE SLEEVE 160 927.

-1шт.

|$74

-1шт.
