Запчасти Komatsu D39E-1 КОНЕЧНАЯ ПЕРЕДАЧА И ЗВЕЗДОЧКА ПРИВОД TRAIN

|$0

1261 335 H91

FINAL DRIVE AND SPROCKET

-54шт.

|$1

1261 353 H92

FINAL DRIVE ASSY, LEFT

1шт.

1

1206 069 H1

RING, SEAL - HOUSING

1шт.

2

1284 706 H91

SHAFT, SPROCKET CARRIER

1шт.

3

1214 405 H91

KIT, SEAL

1шт.

4

1209 259 H91

BEARING, TAPERED ROLLER - OUTER

1шт.

|$6

1209 260 H91

CONE, BEARING

1шт.

|$7

1209 261 H1

CUP, BEARING

1шт.

5

1209 262 H91

BEARING, TAPERED ROLLER - INNER

1шт.

|$9

1209 263 H91

CONE, BEARING

1шт.

|$10

170 234 R1

CUP, BEARING

1шт.

6

1208 981 H1

SPACER, BEARING

1шт.

7

1209 669 H1

SHIM, CARRIER - 0.005IN

-2шт.

|$13

1209 670 H1

SHIM, CARRIER - 0.007IN

-2шт.

|$14

1209 671 H1

SHIM, CARRIER - 0.020IN

-2шт.

8

1209 672 H1

WASHER, CARRIER

1шт.

9

25 358 R1

BOLT, HEX - 3/4NCx3-3/4

1шт.

10

1208 982 H1

GASKET, COVER

1шт.

11

1208 983 H1

COVER, CARRIER SHAFT

1шт.

|$19

70 427 R1

BOLT, HEX - 7/16NCx1-1/4

2шт.

|$20

115 314

WASHER, LOCK - 7/16

2шт.

12

1258 203 H92

HOUSING ASSY, LEFT

1шт.

12A

280 668 R91

PLUG, FILL

1шт.

|$23

367 478 R1

PIN, DOWEL

2шт.

|$24

104 939

PLUG, CORK

2шт.

|$25

1284 556 H1

PLUG, THREADED

2шт.

13

621 116 C2

GEAR, SPROCKET DRIVE (68 TEETH)

1шт.

14

621 110 C3

SCREW, RETAINER

1шт.

|$28

454 522 R1

NUT, RETAINER - 1/2NC

1шт.

15

621 125 C2

PINION, DRIVE

1шт.

16

14 969 L

BEARING, TAPERED ROLLER - OUTER

1шт.

|$31

M 93 599

CONE, BEARING

1шт.

|$32

PO 1 403 9

CUP, BEARING

1шт.

16

168 420 R91

BEARING, TAPERED ROLLER - OUTER

1шт.

|$34

168 421 R91

CONE, BEARING

1шт.

|$35

168 422 R1

CUP, BEARING

1шт.

17

29 216 H

BEARING, TAPERED ROLLER - INNER

1шт.

|$37

29 215 H

CONE, BEARING

1шт.

|$38

29 214 H

CUP, BEARING

1шт.

17

94 364 R91

BEARING, TAPERED ROLLER - INNER

1шт.

|$40

94 365 R91

CONE, BEARING

1шт.

|$41

94 366 R1

CUP, BEARING

1шт.

17

56 256 H

BEARING, TAPERED ROLLER - INNER

1шт.

|$43

56 257 H

CONE, BEARING

1шт.

|$44

56 258 H

CUP, BEARING

1шт.

18

621 127 C1

RING, RETAINING - 0.109IN

1шт.

|$46

621 128 C1

RING, RETAINING - 0.101IN

1шт.

|$47

705 473 C1

RING, RETAINING - 0.117IN

1шт.

19

621 129 C92

SEAL, OIL

1шт.

20

280 668 R91

PLUG, DRAIN

1шт.

21

716 900 C1

COVER, HOUSING BOTTOM

1шт.

|$51

24 863 R1

BOLT, HEX - 1/2NCx1-3/4

14шт.

|$52

116 121

WASHER, LOCK - 1/2

14шт.

|$53

26 322 R1

BOLT, HEX - 5/8NCx2

5шт.

|$54

24 878 R1

BOLT, HEX - 5/8NCx2-3/4

2шт.

|$55

25 680 R1

BOLT, HEX - 5/8NCx6

1шт.

|$56

734 324 C1

STUD, MOUNTING - 5/8NC

2шт.

|$57

25 537 R1

WASHER, FLAT - 5/8

10шт.

|$58

25 528 R1

NUT, HEX - 5/8NC

2шт.

|$59

1261 354 H92

FINAL DRIVE ASSY, RIGHT

1шт.

1

1206 069 H1

O-RING, HOUSING

1шт.

2

1284 706 H91

SHAFT, SPROCKET CARRIER

1шт.

3

1214 405 H91

KIT, SEAL

1шт.

4

1209 259 H91

BEARING, TAPERED ROLLER - OUTER

1шт.

|$64

1209 260 H91

CONE, BEARING

1шт.

|$65

1209 261 H1

CUP, BEARING

1шт.

5

1209 262 H91

BEARING, TAPERED ROLLER - INNER

1шт.

|$67

1209 263 H91

CONE, BEARING

1шт.

|$68

170 234 R1

CUP, BEARING

1шт.

6

1208 981 H1

SPACER, BEARING

1шт.

7

1209 669 H1

SHIM, CARRIER - 0.005IN

-2шт.

|$71

1209 670 H1

SHIM, CARRIER - 0.007IN

-2шт.

|$72

1209 671 H1

SHIM, CARRIER - 0.020IN

-2шт.

8

1209 672 H1

WASHER, CARRIER

1шт.

9

25 358 R1

BOLT, HEX - 3/4NCx3-3/4

1шт.

10

1208 982 H1

GASKET, COVER

1шт.

11

1208 983 H1

COVER, CARRIER SHAFT

1шт.

|$77

70 427 R1

BOLT, HEX - 7/16NCx1-1/4

2шт.

|$78

115 314

WASHER, LOCK - 7/16

2шт.

12

1258 205 H92

HOUSING ASSY, RIGHT

1шт.

12A

280 668 R91

PLUG, FILL

1шт.

|$81

367 478 R1

PIN, DOWEL

2шт.

|$82

104 939

PLUG, CORK

2шт.

|$83

1284 556 H1

PLUG, THREADED

2шт.

13

621 116 C2

GEAR, SPROCKET DRIVE (68 TEETH)

1шт.

14

621 110 C3

SCREW, RETAINER

1шт.

|$86

454 522 R1

NUT, RETAINER - 1/2NC

1шт.

15

621 125 C2

PINION, DRIVE

1шт.

16

14 969 L

BEARING, TAPERED ROLLER - OUTER

1шт.

|$89

M 93 599

CONE, BEARING

1шт.

|$90

PO 1 403 9

CUP, BEARING

1шт.

16

168 420 R91

BEARING, TAPERED ROLLER - OUTER

1шт.

|$92

168 421 R91

CONE, BEARING

1шт.

|$93

168 422 R1

CUP, BEARING

1шт.

17

29 216 H

BEARING, TAPERED ROLLER - INNER

1шт.

|$95

29 215 H

CONE, BEARING

1шт.

|$96

29 214 H

CUP, BEARING

1шт.

17

94 364 R91

BEARING, TAPERED ROLLER - INNER

1шт.

|$98

94 365 R91

CONE, BEARING

1шт.

|$99

94 366 R1

CUP, BEARING

1шт.

17

56 256 H

BEARING, TAPERED ROLLER - INNER

1шт.

|$101

56 257 H

CONE, BEARING

1шт.

|$102

56 258 H

CUP, BEARING

1шт.

18

621 127 C1

RING, RETAINING - 0.109IN

1шт.

|$104

621 128 C1

RING, RETAINING - 0.101IN

1шт.

|$105

705 473 C1

RING, RETAINING - 0.117IN

1шт.

19

621 129 C92

SEAL, OIL

1шт.

20

280 668 R91

PLUG, DRAIN

1шт.

21

716 901 C1

COVER, HOUSING BOTTOM

1шт.

|$109

24 863 R1

BOLT, HEX - 1/2NCx1-3/4

14шт.

|$110

116 121

WASHER, LOCK - 1/2

14шт.

|$111

26 322 R1

BOLT, HEX - 5/8NCx2

5шт.

|$112

24 878 R1

BOLT, HEX - 5/8NCx2-3/4

2шт.

|$113

25 680 R1

BOLT, HEX - 5/8NCx6

1шт.

|$114

734 324 C1

STUD, MOUNTING - 5/8NC

2шт.

|$115

25 537 R1

WASHER, FLAT - 5/8

10шт.

|$116

25 528 R1

NUT, HEX - 5/8NC

2шт.

22

1211 902 H2

SPROCKET, CASTED TEETH

2шт.

22

1298 736 H1

SPROCKET, MACHINED TEETH

2шт.

|$119

24 888 R1

BOLT, HEX - 3/4NCx2

24шт.

|$120

25 538 R1

WASHER, FLAT - 3/4

24шт.

|$123

-1шт.

|$122

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$124

-1шт.
