Запчасти Komatsu D39E-1 ТРАНСМИССИЯ ТРАНСМИССИЯ С КЛАПАНОМS ПРИВОД TRAIN

|$0

635 988 C94

TRANSMISSION WITH VALVES

-54шт.

1

HOUSING AND INTERNAL PARTS (SEE PG 07-066)

-29шт.

2

716 912 C2

GASKET, MANIFOLD

1шт.

3

716 911 C1

MANIFOLD, VALVE

1шт.

|$4

24 843 R1

BOLT, HEX - 3/8NCx2

3шт.

|$5

24 841 R1

BOLT, HEX - 3/8NCx1-1/2

8шт.

|$6

25 534 R1

WASHER, FLAT - 3/8

11шт.

4

738 058 C1

STRAINER, ORIFICE - OPTIONAL

1шт.

4

738 444 C1

STRAINER, ORIFICE - OPTIONAL

1шт.

5

VALVE, PRESSURE REGULATOR (SEE PG 07-080)

-29шт.

|$10

24 845 R1

BOLT, HEX - 3/8NCx4

3шт.

|$11

25 534 R1

WASHER, FLAT - 3/8

3шт.

|$12

372 821 R1

RING, SEAL - LARGE

2шт.

|$13

252 707 R1

RING, SEAL - SMALL

2шт.

6

VALVE, RANGE SELECTOR (SEE PG 07-082)

-29шт.

|$15

25 501 R1

BOLT, HEX - 3/8NCx3-3/4

3шт.

|$16

25 534 R1

WASHER, FLAT - 3/8

3шт.

|$17

252 707 R1

RING, SEAL

10шт.

7

VALVE, RATE OF RISE (SEE PG 07-084)

-29шт.

|$19

25 501 R1

BOLT, HEX - 3/8NCx3-3/4

3шт.

|$20

275 804 R1

BOLT, HEX - 3/8NCx3

1шт.

|$21

25 534 R1

WASHER, FLAT - 3/8

4шт.

8

657 951 C3

GASKET, VALVE

1шт.

9

709 590 C1

TUBE, SCAVENGE

1шт.

10

734 040 C2

GASKET, SCAVENGE TUBE

1шт.

11

9410 358

PLUG, PORT

1шт.

|$26

364 839 R1

RING, SEAL

1шт.

|$$28

-1шт.

|$28

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$30

-1шт.

|$$31

-1шт.

|$31

F2 - PART OF TRANSMISSION SERVICE KIT 741 453 C93.

-1шт.

|$$33

-1шт.
