Запчасти Komatsu D39E-1 ГОЛОВКА ЦИЛИНДРОВ POWER

|$0

6731-11-1220

CYLINDER HEAD ASSEMBLY

1шт.

1

NSS

HEAD, CYLINDER

1шт.

2

6736-11-1160

PLUG, EXPANSION

3шт.

3

6732-11-1930

PLUG, PIPE

2шт.

4

6732-11-1910

PLUG. PIPE (1/2 NPT)

5шт.

|$5

6736-41-4110

INTAKE VALVE ASSEMBLY

4шт.

5

NSS

VALVE, INTAKE

1шт.

6

6732-41-4520

COLLET, VALVE

2шт.

|$8

6736-41-4210

EXHAUST VALVE ASSEMBLY

4шт.

7

NSS

VALVE, EXHAUST

1шт.

8

6732-41-4520

COLLET, VALVE

2шт.

9

6732-41-4410

SPRING, VALVE

8шт.

10

6732-41-4510

RETAINER, VALVE SPRING

8шт.

11

6732-41-4530

SEAL, INTAKE VALVE STEM

4шт.

12

6732-41-4540

SEAL, EXHAUST VALVE STEM

4шт.

13

6732-11-1610

BOLT (M12x1.75x70)

4шт.

14

6732-11-1620

BOLT (M12x1.75x120)

10шт.

15

6736-19-1440

INSERT, EXHAUST VALVE

-2шт.

16

6736-19-1430

INSERT, INTAKE VALVE

-2шт.

17

6736-19-1310

GUIDE, VALVE STEM (THICK WALL 60.5MM LONG INTAKE)

-2шт.

18

6736-19-1410

GUIDE, VALVE STEM (THICK WALL 51.75MM LONG EXH)

-2шт.

19

6736-18-1310

GUIDE, VALVE STEM (THIN WALL, INTAKE AND EXH)

-2шт.

20

6732-11-1151

GASKET, CYLINDER HEAD

1шт.
