Запчасти Komatsu D39E-1 ПЕРЕКОС. ОТВАЛА SECTION ГИДРАВЛS

|$0

1299 224 H91

SECTION ASSY, BLADE TILT

1шт.

1

POSITIONER, SPOOL (SEE PG 10-052)

-29шт.

2

VALVE, LOAD CHECK (SEE PG 10-054)

-29шт.

|$3

1299 238 H91

SEAL ASSY, SPOOL

-54шт.

3

850 880 C1

RETAINER, SEAL

1шт.

|$5

1299 239 H1

KIT, SEAL

1шт.

4

NSS

RING, BACK UP

1шт.

5

NSS

RING, SEAL

1шт.

|$8

1299 240 H1

KIT, SEAL PLATE

1шт.

6

NSS

PLATE, SEAL

1шт.

|$10

NSS

BOLT, HEX - 1/4NCx1/2

2шт.

7

NSS

SPOOL, SECTION

1шт.

8

NSS

HOUSING, SECTION

1шт.

|$$14

-1шт.

|$14

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$16

-1шт.

|$$17

-1шт.

|$17

F2 - FOR SHIPPING PURPOSES ONLY. USE FOR SERVICING SECTION.

-1шт.

|$$19

-1шт.
