Запчасти Komatsu D39E-1 ЗАДН. ОСНОВН. РАМА РАМА

|$0

706 173 C92

FRAME ASSY, REAR MAIN

1шт.

1

NSS

FRAME, REAR MAIN

1шт.

2

621 546 C1

DOWEL, SHOE

8шт.

3

621 547 C1

DOWEL, FINAL DRIVE

4шт.

4

621 090 C91

BEARING, NEEDLE

4шт.

5

613 908 C1

PLUG, PIPE

4шт.

6

271 647 R1

PLUG, DRAIN

1шт.

7

601 093 C1

PLUG, CUP

2шт.

8

652 817 C1

TUBE, BRAKE ROD

1шт.

9

621 549 C1

INSERT, ADJUSTING BOLT

2шт.

10

104 942

PLUG, CORK - #6

-2шт.

11

117 926

PLUG, CORK - #12

-2шт.

12

23 624 R1

PLUG, CUP

4шт.

|$$14

-1шт.

|$14

F1 - SERVICE PART WILL BE AVAILABLE ON SPECIAL ORDER WITH THE CLEARANCE

-1шт.

|$15

OF THE ENGINEERING DEPARTMENT. PRODUCT IDENTIFICATION NUMBER (PIN)

-1шт.

|$16

MUST BE FURNISHED WHEN ORDERING. ORDER ON MACHINE ORDER FORM.

-1шт.
