Запчасти Komatsu D39E-1 РАМАS И СОЕДИН-ЕS РАМА

|$0

1308 343 H91

FRAME AND CONNECTIONS

-54шт.

|$1

1306 389 H91

FRAME ASSY, FRONT

1шт.

1

NSS

FRAME, FRONT

1шт.

2

NSS

CAP, MOUNTING

2шт.

|$4

25 646 R1

BOLT, HEX - 1NCx2-3/4

4шт.

|$5

25 550 R1

WASHER, FLAT - 1

4шт.

|$6

25 740 R1

BOLT, HEX - 7/8NCx2-3/4

6шт.

|$7

25 910 R1

BOLT, HEX - 7/8NCx3-1/4

2шт.

|$8

25 760 R1

BOLT, HEX - 7/8NCx3-1/2

2шт.

|$9

622 015 C1

BOLT, SAFETY - 7/8NCx5

2шт.

|$10

25 530 R1

NUT, HEX - 7/8

2шт.

|$11

277 606 R1

WASHER, FLAT - 29/64

10шт.

3

1261 705 H1

BAR, TIE

2шт.

|$13

341 811 R1

WASHER, FLAT

2шт.

|$14

25 762 R1

NUT, HEX - 1-1/8NC

2шт.

4

1262 805 H1

SHIM, MOUNTING - 0.060IN

-2шт.

|$16

1262 806 H1

SHIM, MOUNTING - 0.030IN

-2шт.

|$17

1262 807 H1

SHIM, MOUNTING - 0.015IN

-2шт.

5

620 862 C1

SPACER, TIE BAR

2шт.

6

308 872 R1

CLIP, CLOSED

1шт.

|$20

24 839 R1

BOLT, HEX - 3/8NCx3/4

1шт.

|$21

25 544 R1

WASHER, FLAT - 3/8

1шт.

7

FRAME, REAR (SEE PG 09-006)

-29шт.

8

717 260 C1

GASKET WITH SPACERS, COVER

1шт.

9

1306 726 H91

COVER, REAR FRAME

1шт.

|$25

24 841 R1

BOLT, HEX - 3/8NCx1-1/2

26шт.

|$26

25 534 R1

WASHER, FLAT - 3/8

26шт.

10

1281 074 H91

TUBE, UPPER FILLER

1шт.

11

1281 072 H91

TUBE, LOWER FILLER

1шт.

12

1281 725 H1

DIPSTICK

1шт.

13

733 040 C2

PLATE, PTO COVER

1шт.

|$31

26 957 R1

BOLT, HEX - 5/8NCx1

6шт.

|$32

259 190 R1

O-RING, COVER

1шт.

14

621 575 C1

STIFFENER, SIDE

2шт.

15

621 576 C1

STIFFENER, FRONT OR BACK

2шт.

16

662 250 C1

BREATHER, REAR FRAME - OPTIONAL

1шт.

16

666 156 C1

BREATHER, REAR FRAME - OPTIONAL

1шт.

17

105 407

NIPPLE, PIPE

1шт.

18

105 413

ELBOW - 90°

1шт.

19

706 443 C2

BAFFLE, REAR FRAME SUMP

1шт.

|$40

27 879 R1

BOLT, HEX - 1/2NCx3/4

2шт.

|$41

25 536 R1

WASHER, FLAT - 1/2

2шт.

20

1268 300 H1

BEARING, NON-LUBE

2шт.

21

1268 301 H1

SEAL, PIN

4шт.

22

1284 563 H1

LINK, RADIATOR

1шт.

|$45

140 483 H

BOLT, HEX - 3/8NCx1-1/4

2шт.

|$46

178 372 R1

WASHER, FLAT - 13/32

4шт.

23

625 875 C1

MOUNT, SHOCK

2шт.

|$48

1308 685 H91

DOOR, RADIATOR GUARD

-54шт.

24

1306 805 H1

DOOR, RADIATOR

1шт.

|$50

26 317 R1

BOLT, HEX - 1/2NCx1-1/4

6шт.

|$51

25 546 R1

WASHER, FLAT - 1/2

6шт.

|$52

1308 331 H91

DOOR, HEAVY DUTY RADIATOR GUARD

-54шт.

25

1306 806 H1

DOOR, RADIATOR

1шт.

|$54

26 318 R1

BOLT, HEX - 1/2NCx1-1/2

6шт.

|$55

25 546 R1

WASHER, FLAT - 1/2

6шт.

26

GUARD, TRANSMISSION (SEE PG 09-008)

-29шт.

27

GUARD, CRANKCASE (SEE PG 09-008)

-29шт.

28

TRUNNION, LEFT (SEE PG 17-002)

-29шт.

28

TRUNNION, LEFT (SEE PG 17-004)

-29шт.

29

TRUNNION, RIGHT (SEE PG 17-002)

-29шт.

29

TRUNNION, RIGHT (SEE PG 17-004)

-29шт.

|$62

1300 139 H1

ADHESIVE, RMF COVER - 1 QT CONTAINER

1шт.

|$$64

-1шт.

|$64

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$66

-1шт.

|$$67

-1шт.

|$67

F2 - SERVICE PART WILL BE AVAILABLE ON SPECIAL ORDER WITH THE CLEARANCE

-1шт.

|$68

OF THE ENGINEERING DEPARTMENT. PRODUCT IDENTIFICATION NUMBER (PIN)

-1шт.

|$69

MUST BE FURNISHED WHEN ORDERING. ORDER ON MACHINE ORDER FORM.

-1шт.
