Запчасти Komatsu D39E-1 IN ГУСЕНИЦЫS D9P- КОЛЕСА И TRACTION

|$0

1281 176 H91

TRACK SHOES

-54шт.

1

1236 987 H1

SHOE, TRACK

78шт.

2

616 199 C4

BOLT, TRACK SHOE

304шт.

3

616 200 C1

NUT, TRACK SHOE

304шт.

4

1258 970 H91

BAR, C-FRAME RUB

2шт.

|$5

24 875 R1

BOLT, HEX - 5/8NCx2

8шт.

|$6

25 547 R1

WASHER, FLAT - 5/8

8шт.

5

1258 997 H1

SHIM, RUB BAR

-2шт.

6

1281 017 H1

STEP, FOOT

2шт.

|$9

24 874 R1

BOLT, HEX - 5/8NCx1-3/4

4шт.

|$10

25 537 R1

WASHER, FLAT - 5/8

8шт.

|$11

25 528 R1

NUT, HEX - 5/8NC

4шт.

7

BOLT, MASTER LINK (SEE PG 15-010)

-29шт.

|$$14

-1шт.

|$14

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$16

-1шт.
