Запчасти Komatsu D39E-1 КАПОТ, ПАНЕЛЬS, СУППОРТS И DASH КАБИНА ROPS SUPERSTRUCTURE

1

1304 451 H91

DASHBOARD

1шт.

|$1

24 861 R1

BOLT, HEX - 1/2NCx1-1/4

6шт.

|$2

25 546 R1

WASHER, FLAT - 1/2

6шт.

2

1286 760 H2

SHIM, MOUNTING

-2шт.

3

1308 145 H1

BAR, DASH BRACE

2шт.

|$5

24 860 R1

BOLT, HEX - 1/2NCx1

4шт.

|$6

25 546 R1

WASHER, FLAT - 1/2

4шт.

4

COWL, DASH (SEE PG 13-034)

-29шт.

5

27 951 R1

PLUG, FRONT LIGHTS BUTTON

4шт.

6

HOOD, SOLID (SEE PG 13-010)

-29шт.

|$10

24 859 R1

BOLT, HEX - 1/2NCx3/4

3шт.

|$11

106 265

WASHER, FLAT - 9/16

3шт.

6

HOOD, PERFORATED (SEE PG 13-012)

-29шт.

|$13

24 859 R1

BOLT, HEX - 1/2NCx3/4

3шт.

|$14

106 265

WASHER, FLAT - 9/16

3шт.

7

DOOR, LEFT SIDE (SEE PG 13-014)

-29шт.

|$16

26 309 R1

BOLT, HEX - 3/8NCx3/4

3шт.

|$17

25 553 R1

WASHER, FLAT - 3/8

3шт.

|$18

26 317 R1

BOLT, HEX - 1/2NCx1-1/4

2шт.

|$19

25 555 R1

WASHER, FLAT - 1/2

2шт.

8

DOOR, RIGHT SIDE (SEE PG 13-014)

-29шт.

|$21

26 309 R1

BOLT, HEX - 3/8NCx3/4

3шт.

|$22

25 553 R1

WASHER, FLAT - 3/8

3шт.

|$23

26 317 R1

BOLT, HEX - 1/2NCx1-1/4

2шт.

|$24

25 555 R1

WASHER, FLAT - 1/2

2шт.

9

679 070 C1

INSULATOR, AIR STACK

1шт.

10

1277 041 H91

COVER, REAR

1шт.

|$27

24 860 R1

BOLT, HEX - 1/2NCx1

2шт.

|$28

25 546 R1

WASHER, FLAT - 1/2

2шт.

11

1277 043 H1

COVER, ACCESS

1шт.

|$30

24 839 R1

BOLT, HEX - 3/8NCx3/4

1шт.

|$31

25 534 R1

WASHER, FLAT - 3/8

1шт.

|$32

126 032

NUT, WING - 3/8NC

1шт.

12

1281 995 H92

BRACKET, HOOD TIE DOWN

2шт.

|$34

25 483 R1

BOLT, HEX - 1/4NCx1

4шт.

|$35

25 542 R1

WASHER, FLAT - 1/4

4шт.

13

1281 994 H1

ROD, TIE DOWN

2шт.

|$37

25 543 R1

WASHER, FLAT - 5/16

4шт.

|$38

9413 952

NUT, LOCK - 5/16NC

2шт.

14

617 867 C1

BALL, COMPRESSION

2шт.
