Запчасти Komatsu D39E-1 ПЕРЕДН. ПРИВОД COVER POWER

1

6736-21-3210

BOLT - M8x50

10шт.

2

1258 941 H1

BOLT - M8x60

1шт.

|$2

1294 346 H91

COVER ASSY, GEAR

1шт.

3

1240 674 H1

FRONT SEAL SERVICE KIT

1шт.

4

1240 232 H1

COVER, GEAR

1шт.

5

6732-21-3160

SCREW, CAP - M5x17

2шт.

6

1258 942 H1

RETAINER, BELT

1шт.

|$7

1258 943 H91

HOUSING ASSY, TIMING PIN

1шт.

7

6732-21-3140

PIN, TIMING

1шт.

8

6732-21-3150

RING, RETAINING

1шт.

9

6732-21-3870

SEAL, O RING

1шт.

10

6732-21-3180

HOUSING, TIMING PIN

1шт.

11

1241 652 H1

GASKET, GEAR COVER

1шт.

12

1241 284 H2

SEAL, RECTANGULAR RING

1шт.

13

1240 382 H2

GASKET, GEAR HOUSING

1шт.

14

1242 027 H1

HOUSING, GEAR

1шт.

15

1304 664 H1

BOLT - M8x16

11шт.

16

1307 190 H1

BOLT - M8x20

5шт.
