Запчасти Komatsu D39E-1 ГОЛОВКА ЦИЛИНДРОВ POWER

|$0

1295 764 H91

HEAD ASSY, CYLINDER

1шт.

1

NSS

HEAD, CYLINDER

1шт.

2

1240 200 H1

PLUG, EXPANSION

3шт.

5

6732-11-1930

PLUG, PIPE

2шт.

6

6732-11-1910

PLUG, PIPE

5шт.

|$5

1240 104 H91

VALVE ASSY, INTAKE

4шт.

8

NSS

VALVE, INTAKE

4шт.

14

6732-41-4520

COLLET, VALVE

8шт.

|$8

1240 105 H91

VALVE ASSY, EXHAUST

4шт.

9

NSS

VALVE, EXHAUST

4шт.

14

6732-41-4520

COLLET, VALVE

8шт.

10

6732-41-4530

SEAL, VALVE STEM

8шт.

12

6735-41-4410

SPRING, VALVE

8шт.

13

6732-41-4510

RETAINER, VALVE SPRING

8шт.

3

1295 765 H1

TUBE, AFTERCOOLER

1шт.

15

6732-11-1620

BOLT - M12x120

10шт.

16

6732-11-1610

BOLT - M12x70

4шт.

17

6732-11-1810

GASKET, CYLINDER HEAD (STD)

1шт.

|$18

1295 467 H2

GASKET, CYLINDER HEAD (0.25MM OVERSIZE)

-2шт.

|$19

1240 785 H3

GASKET, CYLINDER HEAD (0.50MM OVERSIZE)

-2шт.

18

6736-19-1440

INSERT, VALVE (EXHAUST)

-2шт.

19

6736-19-1430

INSERT, VALVE (INTAKE)

-2шт.

20

6736-19-1310

GUIDE, VALVE (THICK WALL 60.5MM LONG INT)

-2шт.

21

6736-19-1410

GUIDE, VALVE (THICK WALL 51.75MM LONG EXH)

-2шт.

22

6736-18-1310

GUIDE, VALVE (THIN WALL, INTAKE EXHAUST)

-2шт.

|$28

-1шт.

|$26

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$27

ASSEMBLIES CATALOG.

-1шт.
