Запчасти Komatsu D38E-1A FIG. R-A LUBRICATED ГУСЕНИЦЫ СИСТЕМА - ОДИНОЧН. NOTCH SPLIT СОЕДИНИТЕЛЬН. ЗВЕНО ХОДОВАЯ

|$0

1306 624 H91

LUBRICATED TRACK SYSTEM

SN: P086301 --UP

1шт.

|$1

1281 310 H91

CHAIN ASSEMBLY, TRACK

SN: P086301 --UP

2шт.

1

1236 887 H1

LINK, SPLIT - RIGHT - PIN END

SN: P086301 --UP

1шт.

2

1236 886 H1

LINK, SPLIT - LEFT - PIN END

SN: P086301 --UP

1шт.

3

1237 191 H1

BUSHING, CHAIN LINK

SN: P086301 --UP

37шт.

4

1237 193 H1

PIN, CHAIN LINK

SN: P086301 --UP

37шт.

5

1237 196 H1

WASHER, THRUST

SN: P086301 --UP

74шт.

6

1236 891 H1

LINK, CHAIN - RIGHT

SN: P086301 --UP

36шт.

7

1236 890 H1

LINK, CHAIN - LEFT

SN: P086301 --UP

36шт.

8

1236 888 H1

LINK, SPLIT - LEFT - BUSHING END

SN: P086301 --UP

1шт.

9

1236 889 H1

LINK, SPLIT - RIGHT - BUSHING END

SN: P086301 --UP

1шт.

10

739 158 C1

PLUG, PIN

SN: P086301 --UP

37шт.

11

1252 955 H91

SEAL, CHAIN

SN: P086301 --UP

74шт.

|$13

1236 990 H2

BOLT, SPLIT LINK TRACK SHOE

SN: P086301 --UP

4шт.

|$14

1281 304 H91

CHAIN, WITH 15 IN SHOES - D38E-1A

SN: P086301 --UP

2шт.

|$15

CHAIN, TRACK - SEE ABOVE

SN: P086301 --UP

1шт.

|$16

SHOE, TRACK (SEE FIG. R0500-01A0)

SN: P086301 --UP

37шт.

|$17

616 199 C4

BOLT, TRACK SHOE

SN: P086301 --UP

144шт.

|$18

616 200 C1

NUT, SHOE BOLT

SN: P086301 --UP

144шт.

|$19

1281 305 H91

CHAIN, WITH 15 IN SHOES - MUD RELIEFTYPE - D38E-1A

SN: P086301 --UP

2шт.

|$20

CHAIN, TRACK - SEE ABOVE

SN: P086301 --UP

1шт.

|$21

SHOE, TRACK (SEE FIG. R0500-01A0)

SN: P086301 --UP

37шт.

|$22

616 199 C4

BOLT, TRACK SHOE

SN: P086301 --UP

144шт.

|$23

616 200 C1

NUT, SHOE BOLT

SN: P086301 --UP

144шт.

|$24

1281 306 H91

CHAIN, WITH 17 IN SHOES - D38E-1A

SN: P086301 --UP

2шт.

|$25

CHAIN, TRACK - SEE ABOVE

SN: P086301 --UP

1шт.

|$26

SHOE, TRACK (SEE FIG. R0500-01A1)

SN: P086301 --UP

37шт.

|$27

616 199 C4

BOLT, TRACK SHOE

SN: P086301 --UP

144шт.

|$28

616 200 C1

NUT, SHOE BOLT

SN: P086301 --UP

144шт.

|$29

1281 307 H91

CHAIN, WITH 24 IN SHOES - D38P-1A

SN: P086301 --UP

2шт.

|$30

CHAIN, TRACK - SEE ABOVE

SN: P086301 --UP

1шт.

|$31

SHOE, TRACK (SEE FIG. R0500-01A2)

SN: P086301 --UP

37шт.

|$32

616 199 C4

BOLT, TRACK SHOE

SN: P086301 --UP

144шт.

|$33

616 200 C1

NUT, SHOE BOLT

SN: P086301 --UP

144шт.

|$34

-1шт.

|$35

-1шт.

|$36

-1шт.

|$37

-1шт.

|$38

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$39

-1шт.
