Запчасти Komatsu D38E-1 FOUR СЕКЦ. УПРАВЛЯЮЩ. КЛАПАН ГИДРАВЛS

|$0

1277 082 H91

VALVE ASSY, FOUR SPOOL CONTROL

1шт.

|$1

1299 222 H91

COVER ASSY, INLET

1шт.

1

NSS

COVER, INLET

1шт.

2

VALVE, SYSTEM RELIEF (SEE PG 10-042)

-29шт.

3

9410 361

PLUG, PORT

1шт.

|$5

368 269 R1

RING, SEAL

1шт.

4

SECTION, BLADE LIFT (SEE PG 10-044)

-29шт.

5

SECTION, BLADE TILT (SEE PG 10-046)

-29шт.

6

SECTION, BLADE ANGLE (SEE PG 10-048)

-29шт.

7

SECTION, RIPPER (SEE PG 10-048)

-29шт.

|$10

1299 226 H91

COVER ASSY, OUTLET

1шт.

8

NSS

COVER, OUTLET

1шт.

9

9410 362

PLUG, PORT

1шт.

|$13

297 459 R1

RING, SEAL

1шт.

|$14

1299 227 H1

KIT, BETWEEN SECTION

5шт.

10

NSS

RING, SEAL

2шт.

11

NSS

RING, SEAL

2шт.

|$17

1299 229 H1

KIT, STUD

1шт.

12

NSS

BOLT, MOUNTING

3шт.

13

NSS

NUT, HEX

3шт.

|$$21

-1шт.

|$21

F1 - SEAL KIT CONTAINS 2 SETS OF SEAL RINGS NOT USED ON THIS VALVE.

-1шт.

|$$23

-1шт.
