Запчасти Komatsu D38E-1 ОБОРУД-Е КЛАПАН УПРАВЛ-ЕS FOUR СЕКЦ. КЛАПАН ГИДРАВЛS

|$0

1270 686 H91

EQUIPMENT VALVE CONTROLS

-54шт.

|$1

VALVE, FOUR SPOOL (SEE PG 10-040)

-29шт.

|$2

26 269 R1

BOLT, HEX - 5/16NCx2-3/4

3шт.

|$3

25 533 R1

WASHER, FLAT - 5/16

3шт.

1

CONTROL BRACKET AND HANDLE (SEE PG 10-032)

-29шт.

|$5

25 483 R1

BOLT, HEX - 1/4NCx1

2шт.

|$6

25 487 R1

BOLT, HEX - 1/4NCx1-1/2

2шт.

|$7

25 532 R1

WASHER, FLAT - 1/4

4шт.

2

BOOT, LEVER

1шт.

3

1269 024 H2

BOOT, LEVER

1шт.

4

935 522 C1

STRAP, TIE

1шт.

5

RETAINER, BOOT - W/O MOUNTING INSERTS

1шт.

|$12

25 752 R1

BOLT, HEX - 1/4NCx1/2

4шт.

|$13

25 532 R1

WASHER, FLAT - 1/4

4шт.

6

1306 898 H91

RETAINER, BOOT - WITH MOUNTING INSERTS

1шт.

|$15

160 544

SCREW, PAN - 1/4NCx3/4

4шт.

7

LEVER, FOURTH SPOOL (SEE PG 10-036)

-29шт.

8

114-43-48381

GROMMET

1шт.

|$$19

-1шт.

|$19

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$21

-1шт.

|$$22

-1шт.

|$22

F2 - WITHOUT LAMINATED BOTTOM, FOR REPLACEMENT ORDER THE FOLLOWING PART;

-1шт.

|$23

1269 024 H2

BOOT, LEVER

1шт.

|$$25

-1шт.

|$25

IT IS ALSO RECOMMENDED THAT THE BOOT RETAINER BE REPLACED WITH THE

-1шт.

|$26

FOLLOWING PARTS;

-1шт.

|$27

1306 898 H91

RETAINER, BOOT - WITH MOUNTING INSERTS

1шт.

|$28

160 544

SCREW, PAN - 1/4NCx3/4

4шт.

|$$30

-1шт.

|$30

F3 - WITH LAMINATED BOOT BOTTOM.

-1шт.

|$$32

-1шт.

|$$33

-1шт.

|$33

F4 - FOR REPLACEMENT OF THE INSERTLESS BOOT RETAINER, ORDER THE FOLLOWING

-1шт.

|$34

PARTS;

-1шт.

|$35

1306 898 H91

RETAINER, BOOT - WITH MOUNTING INSERTS

1шт.

|$36

160 544

SCREW, PAN - 1/4NCx3/4

4шт.

|$$38

-1шт.

|$38

IT IS RECOMMENDED THAT THE BOOT BE REPLACED WITH THE FOLLOWING PART;

-1шт.

|$39

1269 024 H2

BOOT, LEVER

1шт.
