Запчасти Komatsu D38E-1 ОБОРУД-Е КЛАПАН УПРАВЛ-ЕS THREE СЕКЦ. КЛАПАН ГИДРАВЛS

|$0

1269 109 H91

EQUIPMENT VALVE CONTROLS

-54шт.

|$1

VALVE, THREE SPOOL (SEE PG 10-038)

-29шт.

|$2

26 269 R1

BOLT, HEX - 5/16NCx2-3/4

3шт.

|$3

25 533 R1

WASHER, FLAT - 5/16

3шт.

1

CONTROL BRACKET AND HANDLE (SEE PG 10-032)

-29шт.

|$5

25 483 R1

BOLT, HEX - 1/4NCx1

2шт.

|$6

25 487 R1

BOLT, HEX - 1/4NCx1-1/2

2шт.

|$7

25 532 R1

WASHER, FLAT - 1/4

4шт.

2

BOOT, LEVER

1шт.

3

1269 024 H2

BOOT, LEVER

1шт.

4

935 522 C1

STRAP, TIE

1шт.

5

RETAINER, BOOT - W/O MOUNTING INSERTS

1шт.

|$12

25 752 R1

BOLT, HEX - 1/4NCx1/2

4шт.

|$13

25 532 R1

WASHER, FLAT - 1/4

4шт.

6

1306 898 H91

RETAINER, BOOT - WITH MOUNTING INSERTS

1шт.

|$15

160 544

SCREW, PAN - 1/4NCx3/4

4шт.

|$$17

-1шт.

|$17

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$19

-1шт.

|$$20

-1шт.

|$20

F2 - WITHOUT LAMINATED BOTTOM, FOR REPLACEMENT ORDER THE FOLLOWING PART;

-1шт.

|$21

1269 024 H2

BOOT, LEVER

1шт.

|$$23

-1шт.

|$23

IT IS ALSO RECOMMENDED THAT THE BOOT RETAINER BE REPLACED WITH THE

-1шт.

|$24

FOLLOWING PARTS;

-1шт.

|$25

1306 898 H91

RETAINER, BOOT - WITH MOUNTING INSERTS

1шт.

|$26

160 544

SCREW, PAN - 1/4NCx3/4

4шт.

|$$28

-1шт.

|$28

F3 - WITH LAMINATED BOOT BOTTOM.

-1шт.

|$$30

-1шт.

|$$31

-1шт.

|$31

F4 - FOR REPLACEMENT OF THE INSERTLESS BOOT RETAINER, ORDER THE FOLLOWING

-1шт.

|$32

PARTS;

-1шт.

|$33

1306 898 H91

RETAINER, BOOT - WITH MOUNTING INSERTS

1шт.

|$34

160 544

SCREW, PAN - 1/4NCx3/4

4шт.

|$$36

-1шт.

|$36

IT IS ALSO RECOMMENDED THAT THE BOOT BE REPLACED WITH THE FOLLOWING

-1шт.

|$37

PART;

-1шт.

|$38

1269 024 H2

BOOT, LEVER

1шт.
