Запчасти Komatsu D38E-1 РУЛЕВ. УПРАВЛЕНИЕ ПРИВОД ПРИВОД TRAIN

|$0

679 191 C91

STEERING DRIVE

-54шт.

1

716 938 C1

CARRIER, PLANET GEAR

2шт.

2

194 298 R1

RING, RETAINING

2шт.

3

629 839 C1

GEAR, PLANET

6шт.

4

629 836 C91

KIT, NEEDLE BEARING - TWO REQUIRED PER GEAR

-2шт.

|$5

NSS

NEEDLE, BEARING

20шт.

5

629 838 C1

SPACER, NEEDLE BEARING

6шт.

6

716 939 C1

SHAFT, PLANET GEAR

6шт.

|$8

19 955 R1

PIN, SPRING - 1/4x1/2

6шт.

7

659 543 C1

WASHER, THRUST

12шт.

8

629 248 C91

GEAR SET, RING AND PINION

1шт.

|$11

24 998 R1

BOLT, HEX - 3/4NFx4 - PINION GEAR

1шт.

|$12

734 204 C1

BOLT, HEX - 7/16NFx7/8 - RING GEAR

12шт.

9

622 260 C1

PLATE, RETAINER

1шт.

10

621 059 C1

CARRIER, RING GEAR

1шт.

11

372 181 R91

BEARING, TAPERED ROLLER - OPTIONAL

2шт.

|$16

372 182 R91

CONE, BEARING

1шт.

|$17

92 575 H

CUP, BEARING

1шт.

11

372 183 R91

BEARING, TAPERED ROLLER - OPTIONAL

2шт.

|$19

372 184 R91

CONE, BEARING

1шт.

|$20

74 420 R1

CUP, BEARING

1шт.

11

621 063 C91

BEARING, TAPERED ROLLER - OPTIONAL

2шт.

|$22

622 200 C91

CONE, BEARING

1шт.

|$23

622 201 C1

CUP, BEARING

1шт.

|$24

621 064 C91

CARRIER ASSY, BEARING

1шт.

12

NSS

CARRIER, BEARING

1шт.

13

621 066 C1

BUSHING, CARRIER

2шт.

|$27

26 974 R1

BOLT, HEX - 7/16NCx1-1/2

12шт.

|$28

25 545 R1

WASHER, FLAT - 7/16

12шт.

14

621 076 C1

SHIM, CARRIER - 0.005IN

-2шт.

|$30

621 077 C1

SHIM, CARRIER - 0.007IN

-2шт.

|$31

621 078 C1

SHIM, CARRIER - 0.020IN

-2шт.

15

621 068 C2

GEAR, SUN

2шт.

16

621 069 C1

RING, RETAINING

4шт.

17

621 070 C92

DISC ASSY, CLUTCH

2шт.

|$35

23 394 R1

RIVET - 1/4x1-3/8

4шт.

18

621 073 C93

DISC ASSY, BRAKE

2шт.

|$37

140 483 H

BOLT, HEX - 3/8NCx1-1/4

12шт.

|$38

25 534 R1

WASHER, FLAT - 3/8

24шт.

|$39

9413 979

NUT, LOCK - 3/8NC

12шт.

|$$41

-1шт.

|$41

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$43

-1шт.
