Запчасти Komatsu D38E-1 ПРИВОД TRAIN ТРУБЫ РАМА - ФИЛЬТР - НАСОС - ФИЛЬТР. ПРИВОД TRAIN

1

709 475 C1

TUBE, RMF SUCTION

1шт.

|$1

343 909 R1

RING, SEAL

1шт.

2

877 949 C2

FLANGE, SPLIT

2шт.

|$3

24 621 R1

BOLT, HEX - 3/8NCx2-1/4

4шт.

3

1285 372 H1

HOSE, TUBE TO STRAINER

1шт.

|$5

343 906 R1

RING, SEAL - AT TUBE

1шт.

4

9410 981

ELBOW, 90°

2шт.

|$7

296 247 R1

RING, SEAL

2шт.

5

932 449 C1

HOSE, STRAINER TO PUMP

1шт.

6

9410 207

CONNECTOR

1шт.

|$10

296 247 R1

RING, SEAL

1шт.

7

9410 231

CONNECTOR

1шт.

|$12

368 269 R1

RING, SEAL

1шт.

8

1280 340 H1

HOSE, PUMP TO FILTER

1шт.

9

150 776 C91

ELBOW, 90° - INLET

2шт.

|$15

296 247 R1

RING, SEAL

2шт.

10

1201 625 C1

HOSE, FILTER TO VALVE TEE

1шт.

|$17

317 262 R1

CLAMP, HOSE

1шт.

11

9410 335

TEE, AT VALVE

1шт.

12

STRAINER, SUCTION (SEE PG 07-022)

-29шт.

|$20

24 839 R1

BOLT, HEX - 3/8NCx3/4

2шт.

|$21

25 534 R1

WASHER, FLAT - 3/8

2шт.

13

709 176 C3

BRACKET, MOUNTING

1шт.

|$23

24 840 R1

BOLT, HEX - 3/8NCx1

2шт.

|$24

25 534 R1

WASHER, FLAT - 3/8

2шт.

14

PUMP, CHARGE AND SCAVENGE (SEE PG 07-028)

-29шт.

15

FILTER, PRESSURE (SEE PG 07-024)

-29шт.

|$27

140 483 H

BOLT, HEX - 3/8NCx1-1/4

2шт.

|$28

178 372 R1

WASHER, FLAT - 27/64

4шт.

16

625 875 C1

MOUNT, SHOCK

2шт.

17

ELBOW, 90° - AT M PORT REG VALVE (SEE PG 07-060)

-29шт.

18

HOSE, NEUTRAL VALVE (SEE PG 07-018)

-29шт.

|$32

306 132 C2

STRAP, TIE

-2шт.
