Запчасти Komatsu D38E-1 РОЛИК ЗАЩИТН.S И ЦЕПЬ GUIDES ПОДВЕСКА

|$0

1280 508 H91

TRACK ROLLER SHIELD - STANDARD DUTY - FACTORY

-54шт.

|$1

1297 667 H91

TRACK ROLLER SHIELD - STANDARD DUTY - FIELD

-54шт.

1

1280 509 H91

SHIELD, LEFT ROLLER

2шт.

|$3

24 872 R1

BOLT, HEX - 5/8NCx1-1/4

12шт.

|$4

671 175 C1

WASHER, FLAT

12шт.

2

1280 510 H91

SHIELD, RIGHT ROLLER

2шт.

|$6

24 872 R1

BOLT, HEX - 5/8NCx1-1/4

12шт.

|$7

671 175 C1

WASHER, FLAT

12шт.

3

621 360 C2

SPACER, SHIELD

8шт.

|$9

25 924 R1

BOLT, HEX - 3/4NCx9-1/2

8шт.

|$10

25 538 R1

WASHER, FLAT - 3/4

16шт.

|$11

9413 983

NUT, LOCK - 3/4NC

8шт.

|$12

1300 355 H91

CHAIN GUIDE ROCK DEFLECTOR - STANDARD DUTY -

-54шт.

4

1300 349 H91

GUIDE, LEFT FRONT CHAIN

2шт.

|$14

24 872 R1

BOLT, HEX - 5/8NCx1-1/4

6шт.

|$15

671 175 C1

WASHER, FLAT

6шт.

5

1252 339 H91

GUIDE, LEFT REAR CHAIN

2шт.

|$17

24 872 R1

BOLT, HEX - 5/8NCx1-1/4

6шт.

|$18

671 175 C1

WASHER, FLAT

6шт.

6

621 360 C2

SPACER, GUIDE

4шт.

|$20

25 924 R1

BOLT, HEX - 3/4NCx9-1/2

4шт.

|$21

25 538 R1

WASHER, FLAT - 3/4

8шт.

|$22

9413 983

NUT, LOCK - 3/4NC

4шт.

7

1300 350 H91

GUIDE, RIGHT FRONT CHAIN

2шт.

|$24

24 872 R1

BOLT, HEX - 5/8NCx1-1/4

6шт.

|$25

671 175 C1

WASHER, FLAT

6шт.

8

1252 340 H91

GUIDE, RIGHT REAR CHAIN

2шт.

|$27

24 872 R1

BOLT, HEX - 5/8NCx1-1/4

6шт.

|$28

671 175 C1

WASHER, FLAT

6шт.

9

621 348 C2

DEFLECTOR, LEFT ROCK

2шт.

|$30

24 875 R1

BOLT, HEX - 5/8NCx2

6шт.

|$31

25 547 R1

WASHER, FLAT - 5/8

6шт.

|$32

25 528 R1

NUT, HEX - 5/8NC

6шт.

10

621 349 C2

DEFLECTOR, RIGHT ROCK

2шт.

|$34

24 875 R1

BOLT, HEX - 5/8NCx2

6шт.

|$35

25 547 R1

WASHER, FLAT - 5/8

6шт.

|$36

25 528 R1

NUT, HEX - 5/8NC

6шт.

|$37

1303 744 H91

TRACK ROLLER SHIELD - HEAVY DUTY - FACTORY

-54шт.

|$38

1303 750 H91

TRACK ROLLER SHIELD - HEAVY DUTY - FIELD

-54шт.

11

1303 745 H91

SHIELD, LEFT ROLLER

2шт.

|$40

24 872 R1

BOLT, HEX - 5/8NCx1-1/4

20шт.

|$41

671 175 C1

WASHER, FLAT

20шт.

12

1303 746 H91

SHIELD, RIGHT ROLLER

2шт.

|$43

24 872 R1

BOLT, HEX - 5/8NCx1-1/4

20шт.

|$44

671 175 C1

WASHER, FLAT

20шт.

13

621 360 C2

SPACER, SHIELD

12шт.

|$46

25 924 R1

BOLT, HEX - 3/4NCx9-1/2

12шт.

|$47

25 538 R1

WASHER, FLAT - 3/4

24шт.

|$48

9413 983

NUT, LOCK - 3/4NC

12шт.

14

621 348 C2

DEFLECTOR, LEFT ROCK

2шт.

|$50

24 875 R1

BOLT, HEX - 5/8NCx2

6шт.

|$51

25 547 R1

WASHER, FLAT - 5/8

6шт.

|$52

25 528 R1

NUT, HEX - 5/8

6шт.

15

621 349 C2

DEFLECTOR, RIGHT ROCK

2шт.

|$54

24 875 R1

BOLT, HEX - 5/8NCx2

6шт.

|$55

25 547 R1

WASHER, FLAT - 5/8

6шт.

|$56

25 528 R1

NUT, HEX - 5/8

6шт.

|$62

-1шт.

|$58

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$63

-1шт.

|$64

-1шт.

|$61

F2 - ONLY USED WITHOUT TRACK ROLLER SHIELDS.

-1шт.

|$65

-1шт.
