Артикул
Название
Примечание
Количество
1
SEAT, SUSPENSION (SEE PG 13-040)
-29шт.
|$1
25 552 R1
WASHER, FLAT - 5/16
4шт.
|$2
25 520 R1
NUT, HEX - 5/16NC
4шт.
|$3
1300 487 H91
SEAT AND SUPPORTS
-54шт.
2
1306 182 H1
ARM REST
2шт.
|$5
24 839 R1
BOLT, HEX - 3/8NCx3/4
4шт.
|$6
25 534 R1
WASHER, FLAT - 3/8
4шт.
3
1306 181 H1
BRACKET, MOUNTING
2шт.
|$8
24 839 R1
BOLT, HEX - 3/8NCx3/4
4шт.
|$9
25 534 R1
WASHER, FLAT - 3/8
4шт.
4
1304 125 H91
PLATE, SEAT MOUNTING
1шт.
|$11
24 840 R1
BOLT, HEX - 3/8NCx1
6шт.
|$12
25 553 R1
WASHER, FLAT - 3/8
6шт.
|$13
24 860 R1
BOLT, HEX - 1/2NCx1
3шт.
|$14
25 555 R1
WASHER, FLAT - 1/2
3шт.
5
1300 620 H91
SUPPORT, FRONT SEAT
1шт.
|$16
24 848 R1
BOLT, HEX - 7/16NCx3/4
4шт.
|$17
25 553 R1
WASHER, FLAT - 3/8
4шт.
6
3071 294 R1
BOSS, MOUNTING - TUBE CLAMP
1шт.
7
1300 689 H1
BAR, SEAT MOUNTING
2шт.
|$20
24 840 R1
BOLT, HEX - 3/8NCx1
4шт.
|$21
25 553 R1
WASHER, FLAT - 3/8
4шт.
|$$23
-1шт.
|$23
F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.
-1шт.
|$$25
-1шт.
Выбрано товаров: 25
