Запчасти Komatsu D38E-1 КОЛЕНВАЛ POWER

|$0

6732-31-1100

CRANKSHAFT ASSEMBLY

1шт.

1

NSS

CRANKSHAFT

1шт.

2

6732-21-6150

PIN, ROLL

1шт.

3

6732-31-1211

GEAR, CRANKSHAFT

1шт.

|$4

6732-29-8110

SET, MAIN BEARING - STD

1шт.

4

NSS

BEARING, MAIN UPPER

4шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

5шт.

|$8

6732-28-8100

SET, MAIN BEARING - 0.25MM OVER

1шт.

4

NSS

BEARING, MAIN UPPER

4шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

5шт.

|$12

6732-27-8100

SET, MAIN BEARING - 0.50MM OVER

1шт.

4

NSS

BEARING, MAIN UPPER

4шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

5шт.

|$16

6732-26-8100

SET, MAIN BEARING - 0.75MM OVER

1шт.

4

NSS

BEARING, MAIN UPPER

4шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

5шт.

|$20

6732-25-8100

SET, MAIN BEARING - 1.00MM OVER

1шт.

4

NSS

BEARING, MAIN UPPER

4шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

5шт.

|$24

6736-29-8700

SET, CRANKSHAFT THRUST BRG - 0.50MM OVER

1шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

1шт.

|$27

6736-28-8700

SET, CRANKSHAFT THRUST BRG - 1.00MM OVER

1шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

1шт.

7

6736-39-1221

SLEEVE, WEAR - FRONT CRANK

1шт.

8

6736-39-1140

SLEEVE, WEAR - REAR CRANK

1шт.

|$$33

-1шт.

|$33

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$34

ASSEMBLIES CATALOG.

-1шт.
