Запчасти Komatsu D38E-1 УПРАВЛ-Е ДВИГАТЕЛЕМS POWER

|$0

1311 318 H91

ENGINE CONTROLS

1шт.

1

104 038

CLEVIS, ROD END

1шт.

|$2

25 487 R1

BOLT, HEX - 1/4NCx1-1/2

1шт.

|$3

25 532 R1

WASHER, FLAT - 1/4

4шт.

|$4

26 110 R1

NUT, LOCK - 1/4NC

1шт.

2

1279 059 H1

CLAMP, SPACER

2шт.

3

104 036

CLEVIS, ROD END

1шт.

|$7

28 232 R1

SCREW, SET - 1/4NF

1шт.

|$8

20 791 R1

PIN, CLEVIS

1шт.

|$9

103 361

PIN, COTTER

1шт.

4

1280 178 H1

CONNECTOR, REDUCER

1шт.

5

1309 771 H1

ROD, PUMP CONTROL

1шт.

|$12

25 523 R1

NUT, CONNECTOR - 3/8NF

2шт.

6

1309 772 H1

LEVER, INJECTION PUMP

1шт.

|$14

30 192 R1

BOLT, MOUNTING - M6x16

2шт.

|$15

30 209 R1

WASHER, FLAT - 6.4M

2шт.

|$16

30 270 R1

WASHER, LOCK

2шт.

7

1300 764 H91

LEVER, CONTROL

1шт.

8

16 619 R1

PIN, CLEVIS

1шт.

|$19

25 536 R1

WASHER, FLAT - 1/2

1шт.

|$20

103 384

PIN, COTTER - 1/8x3/4

1шт.

9

628 588 C1

KNOB, CONTROL LEVER

1шт.

10

1270 331 H91

SHAFT, CONTROL

1шт.

11

303 004 R1

RING, RETAINING

1шт.

|$24

25 538 R1

WASHER, FLAT - 3/4

1шт.

12

1270 705 H1

SPRING, RETURN

1шт.

13

1270 419 H91

RATCHET, ENGINE CONTROL

1шт.

|$27

25 222 R1

BOLT, HEX - 1/4NCx3/4

2шт.

|$28

25 542 R1

WASHER, FLAT - 1/4

2шт.

|$29

1269 045 H91

CONTROL ASSY, THROTTLE

1шт.

14

740 465 C91

BEARING, SEALED - OPTIONAL

2шт.

14

740 766 C91

BEARING, SEALED

2шт.

15

NSS

CONTROL, THROTTLE

1шт.

16

109 454

FITTING, LUBE

1шт.

17

740 528 C1

BOLT, ADJUSTING

2шт.

|$35

25 522 R1

NUT, HEX - 3/6NC

2шт.

|$36

1269 044 H91

OFFSET ASSY, DECELERATOR

1шт.

18

740 465 C91

BEARING, SEALED - OPTIONAL

2шт.

18

740 766 C91

BEARING, SEALED

2шт.

19

NSS

OFFSET, DECELERATOR

1шт.

20

109 454

FITTING, LUBE

1шт.

21

933 123 R1

RING, RETAINING

1шт.

|$42

25 538 R1

WASHER, FLAT - 3/4

1шт.

22

DECELERATOR, OVER TRAVEL (SEE PG 12-018)

-29шт.

|$44

16 617 R1

PIN, CLEVIS - 3/8x1-1/6

1шт.

|$45

103 373

PIN, COTTER - 3/32x3/4

1шт.

23

THROTTLE, OVER TRAVEL (SEE PG 12-020)

-29шт.

|$47

16 617 R1

PIN, CLEVIS - 3/8x1-1/6

1шт.

|$48

103 373

PIN, COTTER - 3/32x3/4

1шт.

24

1258 327 H91

CABLE, THROTTLE

1шт.

|$50

26 030 R1

NUT, HEX - 1/4NF

1шт.

25

281 800 C92

JOINT, BALL - 1/4NF

1шт.

|$52

25 532 R1

WASHER, FLAT - 1/4

1шт.

|$53

27 122 R1

NUT, LOCK - 1/4NF

1шт.

|$54

26 030 R1

NUT, HEX - 1/4NF

1шт.

26

1258 331 H91

BRACKET, CABLE SUPPORT

1шт.

|$56

26 310 R1

BOLT, HEX - 3/8NCx1

2шт.

|$57

25 544 R1

WASHER, FLAT - 3/8

2шт.

27

SWITCH, SHUT OFF (SEE PG 07-120)

-29шт.

28

BRACKET, BRAKE SUPPORT (SEE PG 04-008)

-29шт.

|$$61

-1шт.

|$61

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$63

-1шт.
