Запчасти Komatsu D38E-1 ГЕНЕРАТОР ЭЛЕКТР.

|$0

1302 375 H91

ALTERNATOR ASSY

1шт.

1

NUT, LOCK

1шт.

2

WASHER, LOCK

1шт.

3

1303 792 H1

SPACER, FAN

1шт.

4

1303 793 H1

HOUSING, FRONT

1шт.

5

1303 794 H1

BEARING, FRONT

1шт.

6

1303 795 H1

RETAINER, FRONT BEARING

1шт.

7

1303 791 H1

BOLT, HEX - #10NCx3-5/16

4шт.

8

1303 796 H1

ROTOR

1шт.

9

NSS

BEARING, REAR

1шт.

10

1303 798 H1

STATOR

1шт.

11

1303 797 H1

RETAINER, REAR BEARING

1шт.

12

CAPACITOR

1шт.

13

NSS

TRIO, DIODE

1шт.

|$14

SCREW, MOUNTING

4шт.

14

1303 799 H1

DIODE, POSITIVE RECTIFIER

1шт.

|$16

1303 807 H1

NUT, LOCK - N5

1шт.

15

1303 806 H1

TERMINAL, RING

1шт.

16

1303 800 H1

DIODE, NEGATIVE RECTIFIER

1шт.

17

INSULATOR

2шт.

18

1303 802 H1

INSULATOR

4шт.

19

1303 805 H1

METAL, FLAT - #10

2шт.

20

1303 809 H1

METAL, FLAT - 1/4x9/16

1шт.

21

1303 801 H1

HOUSING, REAR

1шт.

22

1303 790 H1

REGULATOR, VOLTAGE

1шт.

|$25

SCREW, MOUNTING - #8NCx1/2

2шт.

23

1303 789 H1

BRUSH ASSY

1шт.

|$27

SCREW, MOUNTING - #8NCx1/2

2шт.

24

1303 808 H1

INSULATOR, SLEEVE 1/4IDx1/2

1шт.

25

1303 803 H1

INSULATOR, SLEEVE #10x1/3

1шт.

26

1303 804 H1

INSULATOR, SLEEVE #10

1шт.

27

1303 807 H1

NUT, LOCK - N5x.8-1/8TK

5шт.

28

FAN, ALTERNATOR (SEE PG 08-002)

-29шт.

29

PULLEY, ALTERNATOR (SEE PG 12-108)

-29шт.
