Запчасти Komatsu D38E-1 ТРАНСМИССИЯ COMPLETE ТРАНСМИССИЯ ПРИВОД TRAIN

|$0

1306 666 H91

TRANSMISSION ASSY, COMPLETE

1шт.

1

TRANSMISSION WITH VALVES (SEE PG 07-060)

-29шт.

2

1308 378 H1

ELBOW, 90° - M PORT

1шт.

|$3

296 247 R1

RING, SEAL

1шт.

3

380 633 R1

CONNECTOR - C PORT

1шт.

|$5

296 247 R1

RING, SEAL

1шт.

4

105 422

ELBOW, 90°

2шт.

5

161 849

QUICK DISCONNECT

2шт.

6

162 144

CAP, DUST

2шт.

7

585 694 R1

ELBOW, 90°

4шт.

8

667 958 C1

CONNECTOR - L PORT

1шт.

|$11

296 247 R1

RING, SEAL

1шт.

9

9410 202

CONNECTOR - R PORT

1шт.

|$13

364 839 R1

RING, SEAL

1шт.

10

9411 104

ELBOW, 45° - F AND 2 PORTS

2шт.

|$15

364 839 R1

RING, SEAL

2шт.

11

9410 976

ELBOW, 90° - 1 PORT

1шт.

|$17

364 839 R1

RING, SEAL

1шт.

12

662 014 C1

HOSE, R OR 2ND

2шт.

13

336 081 R91

HOSE, F

1шт.

14

717 130 C1

HOSE, 1ST

1шт.

15

9411 107

ELBOW, 45°

1шт.

|$22

368 269 R1

RING, SEAL

1шт.

16

444 613

PLUG, PIPE

1шт.

17

9402 708

CONNECTOR

1шт.

18

9410 254

ELBOW, 45°

1шт.

19

27 843 R1

CLAMP, HOSE

1шт.

20

SLEEVE, PROTECTIVE - 24IN LONG

1шт.

21

TEE, SUPPLY (SEE PG 07-004)

-29шт.

22

VALVE, TRANS/STEERING (SEE PG 07-052)

-29шт.

|$30

160 927

SLEEVE, BULK PROTECTIVE

-2шт.

|$31

741 453 C93

KIT, TRANSMISSION SERVICE

1шт.

|$32

659 910 C1

SEAL PISTON

5шт.

|$33

659 913 C1

RING, SEAL

5шт.

|$34

709 631 C1

SEAL, PISTON

4шт.

|$35

709 632 C1

RING SEAL

4шт.

|$36

659 720 C1

SEAL, PISTON

1шт.

|$37

659 726 C1

RING, SEAL

1шт.

|$38

716 841 C1

RING, SEAL - OPTIONAL

4шт.

|$39

327 090 R3

RING, SEAL - OPTIONAL

4шт.

|$40

22 410 R1

RING, SEAL, COUNTERSHAFT COVER

1шт.

|$41

716 840 C1

RING, SEAL - OPTIONAL

4шт.

|$42

716 747 C1

RING, SEAL - OPTIONAL

4шт.

|$43

707 253 R1

RING, SEAL, REVERSE IDLER SHAFT

1шт.

|$44

21 924 R1

RING, SEAL, OUTPUT SHAFT

2шт.

|$45

301 016 R1

RING, SEAL, ADAPTER FITTING

1шт.

|$46

372 821 R1

RING, SEAL, REG VALVE LARGE

2шт.

|$47

252 707 R1

RING, SEAL, REG SMALL AND SELECTOR VALVE

12шт.

|$48

364 839 R1

RING, SEAL, FITTING

7шт.

|$49

296 247 R1

RING, SEAL, FITTING

3шт.

|$50

368 269 R1

RING, SEAL, LUBE ELBOW

1шт.

|$51

936 658 C1

RING, SEAL, TRANSMISSION CASE

1шт.

|$52

705 495 C1

SHIM, INPUT AND COUNTERSHAFT - 0.005IN

8шт.

|$53

705 496 C1

SHIM, INPUT AND COUNTERSHAFT - 0.007IN

8шт.

|$54

705 497 C1

SHIM, INPUT AND COUNTERSHAFT - 0.030IN

8шт.

|$55

705 492 C1

SHIM, OUTPUT CLUTCH - 0.005IN

8шт.

|$56

705 493 C1

SHIM, OUTPUT CLUTCH - 0.007IN

8шт.

|$57

705 494 C1

SHIM, OUTPUT CLUTCH - 0.030IN

8шт.

|$58

259 246 R1

RING, SEAL, RANGE CLUTCH

1шт.

|$59

621 156 C1

SHIM, TRANS MOUNTING - 0.002IN

4шт.

|$60

621 157 C1

SHIM, TRANS MOUNTING - 0.007IN

4шт.

|$61

621 158 C1

SHIM, TRANS MOUNTING - 0.020IN

8шт.

|$62

716 912 C2

GASKET, MANIFOLD

1шт.

|$63

657 951 C3

GASKET, RATE OF RISE VALVE

1шт.

|$64

734 040 C2

GASKET, SCAVENGE TUBE

1шт.

|$65

666 154 C3

GASKET, PILOT VALVE

1шт.

|$$67

-1шт.

|$67

F1 - PART OF TRANSMISSION SERVICE KIT 741 453 C93.

-1шт.

|$$69

-1шт.

|$$70

-1шт.

|$70

F2 - CUT REQUIRED LENGTH FROM BULK PROTECTIVE SLEEVE 160 927.

-1шт.

|$$72

-1шт.
