Запчасти Komatsu D38E-1 ТУРБОНАГНЕТАТЕЛЬ POWER

|$0

1240 827 H92

TURBOCHARGER ASSY, H1C

1шт.

1

1278 294 H1

HOUSING, COMPRESSOR

1шт.

2

1258 157 H2

DIFFUSER, TURBO

1шт.

3

1240 489 H1

O-RING

1шт.

|$4

1282 514 H91

ROTOR ASSEMBLY

1шт.

4

6736-81-8250

NUT, LOCK

1шт.

5

1240 493 H1

SLINGER, OIL

1шт.

6

1240 494 H1

COLLAR, THRUST

1шт.

7

1278 293 H1

SHAFT AND WHEEL ASSEMBLY

1шт.

8

NSS

IMPELLER, TURBO COMPRESSOR

1шт.

9

1240 698 H1

PLATE, CLAMPING

3шт.

10

1241 169 H1

BOLT - M6x12

6шт.

11

6736-81-8320

SEAL, SPLIT RING

1шт.

12

1246 467 H1

BAFFLE, OIL

1шт.

13

1246 465 H1

SCREW, CAP - M5x16

3шт.

14

1270 365 H1

BEARING, THRUST

1шт.

15

6736-81-8360

RING, RETAINING

4шт.

16

6736-81-8370

BEARING, TURBOCHARGER

2шт.

17

6736-81-8380

BOLT - M8x12

4шт.

18

1258 160 H1

O-RING

1шт.

19

1240 487 H1

PLATE, CLAMPING

2шт.

20

1278 296 H1

BOLT - M6x16

4шт.

|$22

1240 486 H1

LOCKPLATE

2шт.

|$23

1240 506 H1

O-RING

1шт.

21

1240 498 H2

HOUSING, TURBO BEARING

1шт.

22

6736-81-8430

SHIELD, TURBO HEAT

1шт.

23

6736-81-8440

SEAL, SPLIT RING

1шт.

24

1258 159 H1

HOUSING, TURBINE

1шт.

25

1246 470 H1

WASHER, LOCK

6шт.

26

1240 488 H1

PLATE, LOCK

2шт.

27

NSS

DATA PLATE

1шт.

28

6736-81-8480

SCREW, DRIVE

4шт.

29

GASKET, TURBOCHARGER (SEE PG 12-040)

-29шт.

30

GASKET, OIL DRAIN (SEE PG 12-040)

-29шт.

31

6736-51-8140

CONNECTOR, FEMALE

2шт.

32

6736-51-8710

O-RING

1шт.

|$36

1278 104 H91

KIT, TURBO REPAIR

1шт.

|$37

NSS

O-RING

1шт.

|$38

1278 126 H91

KIT, TURBOCHARGER H1C-H2 REPAIR

1шт.

|$$40

-1шт.

|$40

F1 - INCLUDED IN TURBOCHARGER REPAIR H1C-H2 KIT 1278 126 H91

-1шт.

|$$42

-1шт.

|$$43

-1шт.

|$43

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$44

ASSEMBLIES CATALOG.

-1шт.
