Запчасти Komatsu D38E-1 ПАНЕЛЬ ПРИБОРОВ INSTRUMENTS

|$0

1306 506 H91

PANEL AND GAUGES

-54шт.

|$1

1306 507 H91

PANEL ASSY, INSTRUMENT

1шт.

1

1306 420 H91

PANEL, INSTRUMENT

1шт.

2

1306 422 H1

PRODUCT GRAPHIC, PANEL

1шт.

3

CLUSTER, GAUGE (SEE PG 11-006)

-29шт.

|$5

179 389

SCREW, MOUNTING - #10-24x3/4

4шт.

4

1220 651 H2

HOURMETER

1шт.

5

1308 180 H1

SWITCH, START

1шт.

|$8

1308 333 H1

KEY, START

1шт.

|$9

1308 915 H1

NUT, KEY SWITCH

1шт.

6

1306 621 H1

GAUGE, FUEL LEVEL

1шт.

7

606 298 C91

SWITCH, LIGHTING

1шт.

|$12

131 718

WASHER, LOCK - 7/16

1шт.

8

740 347 C1

KNOB, LIGHT SWITCH

1шт.

9

1270 235 H91

LAMP, ILLUMINATION - OPTIONAL

1шт.

9

1283 725 H91

LAMP, ILLUMINATION - OPTIONAL

1шт.

|$16

934 946 R1

WASHER, LOCK - M4

2шт.

10

1134 719 C1

BREAKER, CIRCUIT - 20 AMP

2шт.

|$18

159 339

SCREW, MOUNTING - #6-32x1/2

4шт.

|$19

116 117

WASHER, LOCK - #6

4шт.

|$20

115 997

NUT, HEX - #6-32

4шт.

|$21

106 497

WASHER, LOCK - #10 (TERMINAL)

4шт.

|$22

120 614

NUT, HEX - #10-32 (TERMINAL)

4шт.

11

1432 615 H1

BREAKER, CIRCUIT - 6 AMP

1шт.

|$24

159 339

SCREW, MOUNTING - #6-32x1/2

2шт.

|$25

116 117

WASHER, LOCK - #6

2шт.

|$26

115 997

NUT, HEX - #6-32

2шт.

|$27

106 497

WASHER, LOCK - #10 (TERMINAL)

2шт.

|$28

120 614

NUT, HEX - #10-32 (TERMINAL)

2шт.

12

1306 803 H91

HARNESS, INSTRUMENT PANEL

1шт.

13

1249 210 H1

WIRE, JUMPER

2шт.

14

702 439 C1

MOUNT, RUBBER

4шт.

|$32

178 521

WASHER, LOCK - 1/4

12шт.

|$33

25 519 R1

NUT, HEX - 1/4NC

4шт.

|$34

131 593

NUT, HIGH CROWN - 1/4NC

4шт.

15

1128 402 C1

RECTIFIER DIODE

1шт.

|$36

23 979 R1

SCREW, MOUNTING - #8-18x1/2

2шт.

|$37

131 015

WASHER, FLAT - #8

2шт.

16

20 274 R1

BULB, LAMP - #356

1шт.

17

453 453 C1

SWITCH, ETHER START

1шт.

|$$41

-1шт.

|$41

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$43

-1шт.

|$$44

-1шт.

|$44

F2 - USED WITH ILLUMINATION LAMP 1283 725 H91 ONLY.

-1шт.

|$$46

-1шт.
