Запчасти Komatsu D37PG-5A МАРКИРОВКА (ЯПОН.)(№-) МАРКИРОВКА

|1

134-98-11210

PLATE KIT

SN: 3542-UP

1шт.

1

09653-A0480

PLATE¤ SAFETY,HYDRAULIC TANK

SN: 3886-UP

1шт.

|1

0

PLATE¤ SAFETY,HYDRAULIC TANK

SN: 3542-3885

1шт.

2

09653-A0480

PLATE¤ SAFETY,RADIATOR WARNING

SN: 3886-UP

1шт.

|2

0

PLATE¤ SAFETY,RADIATOR WARNING

SN: 3542-3885

1шт.

3

09654-B0640

PLATE¤ SAFETY,BEFORE AND AFTER OPERATION

SN: 3886-UP

1шт.

|3

0

PLATE¤ CAUTION,BEFORE AND AFTER OPERATION

SN: 3542-3885

1шт.

4

09651-A0640

PLATE¤ SAFETY,BEFORE OPERATING

SN: 3886-UP

1шт.

|4

0

PLATE¤ SAFETY,BEFORE OPERATING

SN: 3542-3884

1шт.

5

09802-10100

PLATE¤ SAFETY,SAFETY COMFIRM OF REAR

SN: 3886-UP

1шт.

|5

0

PLATE¤ CAUTION,SAFETY COMFIRM OF REAR

SN: 3542-3885

1шт.

6

14X-98-11161

PLATE¤ SAFETY,ADJUSTING TRACK SHOE

SN: 3542-UP

1шт.

7

09652-01101

PLATE¤ CAUTION,FUEL TANK

SN: 3542-UP

1шт.

8

09637-01163

PLATE¤ INSTRUCTION,AIR CLEANER

SN: 3542-UP

1шт.

9

103-98-21251

PLATE¤ INSTRUCTION,HYDRAULIC TANK

SN: 3542-UP

1шт.

10

114-98-44250

PLATE¤ OPERATING,PARKING BRAKE LEVER LOCK

SN: 3001-UP

1шт.

11

114-98-44421

PLATE¤ MARK,KOMATSU¤ L.H.

SN: 3937-UP

1шт.

|11

114-98-44420

PLATE¤ MARK,KOMATSU¤ L.H.

SN: 3001-3936

1шт.

|11

114-98-44431

PLATE¤ MARK,KOMATSU¤ R.H.

SN: 3937-UP

1шт.

|11

114-98-44430

PLATE¤ MARK,KOMATSU¤ R.H.

SN: 3001-3936

1шт.

12

09601-00835

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 3001-UP

1шт.

|12

04418-13060

SCREW

SN: 3001-UP

4шт.

13

11G-98-51220

PLATE¤ DATA

SN: 3661-UP

1шт.

14

11G-98-43971

PLATE¤ MARK,D37PG

SN: 3001-UP

2шт.

15

09690-C0224

PLATE¤ MARK,KOMATSU

SN: 3001-UP

1шт.

16

114-98-51111

OIL CHART

SN: 3941-UP

1шт.

|16

114-98-51110

CHART¤ OIL

SN: 3661-3940

1шт.

17

114-98-44250

PLATE¤ OPERATING,BLADE CONTROL LEVER LOCK

SN: 3001-UP

1шт.

18

114-98-51130

PLATE¤ OPERATING,BLADE CONTROL LEVER

SN: 3661-UP

1шт.

19

114-98-44250

PLATE¤ OPERATING,T/M CONTROL LEVER LOCK

SN: 3001-UP

1шт.

20

114-98-44170

PLATE¤ OPERATING,STEERING CONTROL LEVER

SN: 3001-UP

1шт.

21

114-98-44180

PLATE¤ OPERATING,STEERING CONTROL LEVER

SN: 3001-UP

1шт.

22

09963-00101

TAG,DO NOT OPERATE

SN: 3936-UP

1шт.

|22

09963-00101

TAG,DO NOT OPERATE

SN: 3886-3935

1шт.

|22

21X-98-21190

TAG¤ CAUTION,DO NOT OPERATE

SN: 3542-3885

1шт.

23

09667-A0480

PLATE¤ SAFETY,ENGINE ROOM

SN: 3886-UP

1шт.

24

09806-B1200

PLATE¤ SAFETY,KEEP A SAFE DISTANCE

SN: 3886-UP

2шт.

25

09808-A0880

PLATE¤ SAFETY,BATTERY CABLE

SN: 3886-UP

1шт.
