Артикул
Название
Примечание
Количество
|$1
6206-71-1540
INJECTION PUMP ASS'Y
SN: 96999-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 TO A4010-F0A2.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$4
DK105400-7620
GOVERNOR ASS'Y
SN: 96999-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D0A2 AND A4010-E0A2.
-1шт.
1
DK154000-6300
HOUSING
SN: 96999-UP
1шт.
3
DK154007-2900
PLUG
SN: 96999-UP
1шт.
4
DK154007-0200
ADAPTER
SN: 96999-UP
1шт.
5
DK020018-1840
BOLT
SN: 96999-UP
1шт.
6
DK154350-1900
PLATE
SN: 96999-UP
1шт.
7
DK029010-6810
BOLT
SN: 96999-UP
6шт.
8
DK154010-0100
SCREW
SN: 96999-UP
1шт.
10
DK155404-5300
CAP
SN: 96999-UP
1шт.
11
DK154101-0120
FLYWEIGHT ASS'Y
SN: 96999-UP
1шт.
13
DK029231-2030
NUT
SN: 96999-UP
1шт.
14
DK154123-0120
SLEEVE
SN: 96999-UP
1шт.
15
DK029801-0030
BEARING
SN: 96999-UP
1шт.
16
DK029311-0180
SHIM, 0.30MM
SN: 96999-UP
-2шт.
16
DK139410-0000
SHIM, 0.50MM
SN: 96999-UP
-2шт.
16
DK029311-0210
SHIM, 1.00MM
SN: 96999-UP
-2шт.
16
DK139410-0100
SHIM, 1.50MM
SN: 96999-UP
-2шт.
16
DK139410-3100
SHIM, 3.00MM
SN: 96999-UP
-2шт.
16
DK139410-3200
SHIM, 4.00MM
SN: 96999-UP
-2шт.
18
DK154185-1020
CAPSULE,SPRING
SN: 96999-UP
1шт.
19
DK029201-6080
NUT
SN: 96999-UP
1шт.
20
DK154210-0920
GUIDE LEVER ASS'Y
SN: 96999-UP
1шт.
21
DK154230-3920
LINK
SN: 96999-UP
1шт.
22
DK016010-0540
RING,SNAP
SN: 96999-UP
1шт.
23
DK154236-1500
LEVER,TENSION
SN: 96999-UP
1шт.
24
DK154326-5020
LEVER ASS'Y
SN: 96999-UP
1шт.
25
DK154350-7700
GASKET
SN: 96999-UP
1шт.
26
DK154172-3520
CAPSULE,SPRING
SN: 96999-UP
1шт.
27
DK029201-6010
NUT
SN: 96999-UP
1шт.
|$1
6206-71-1540
INJECTION PUMP ASS'Y
SN: 96999-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 TO A4010-F0A2.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$4
DK105400-7620
GOVERNOR ASS'Y
SN: 96999-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D0A2 AND A4010-E0A2.
-1шт.
1
DK154000-6300
HOUSING
SN: 96999-UP
1шт.
3
DK154007-2900
PLUG
SN: 96999-UP
1шт.
4
DK154007-0200
ADAPTER
SN: 96999-UP
1шт.
5
DK020018-1840
BOLT
SN: 96999-UP
1шт.
6
DK154350-1900
PLATE
SN: 96999-UP
1шт.
7
DK029010-6810
BOLT
SN: 96999-UP
6шт.
8
DK154010-0100
SCREW
SN: 96999-UP
1шт.
10
DK155404-5300
CAP
SN: 96999-UP
1шт.
11
DK154101-0120
FLYWEIGHT ASS'Y
SN: 96999-UP
1шт.
13
DK029231-2030
NUT
SN: 96999-UP
1шт.
14
DK154123-0120
SLEEVE
SN: 96999-UP
1шт.
15
DK029801-0030
BEARING
SN: 96999-UP
1шт.
16
DK029311-0180
SHIM, 0.30MM
SN: 96999-UP
-2шт.
16
DK139410-0000
SHIM, 0.50MM
SN: 96999-UP
-2шт.
16
DK029311-0210
SHIM, 1.00MM
SN: 96999-UP
-2шт.
16
DK139410-0100
SHIM, 1.50MM
SN: 96999-UP
-2шт.
16
DK139410-3100
SHIM, 3.00MM
SN: 96999-UP
-2шт.
16
DK139410-3200
SHIM, 4.00MM
SN: 96999-UP
-2шт.
18
DK154185-1020
CAPSULE,SPRING
SN: 96999-UP
1шт.
19
DK029201-6080
NUT
SN: 96999-UP
1шт.
20
DK154210-0920
GUIDE LEVER ASS'Y
SN: 96999-UP
1шт.
21
DK154230-3920
LINK
SN: 96999-UP
1шт.
22
DK016010-0540
RING,SNAP
SN: 96999-UP
1шт.
23
DK154236-1500
LEVER,TENSION
SN: 96999-UP
1шт.
24
DK154326-5020
LEVER ASS'Y
SN: 96999-UP
1шт.
25
DK154350-7700
GASKET
SN: 96999-UP
1шт.
26
DK154172-3520
CAPSULE,SPRING
SN: 96999-UP
1шт.
27
DK029201-6010
NUT
SN: 96999-UP
1шт.
Выбрано товаров: 80
