Запчасти Komatsu 2D68E-N3A СТАРТЕР (.KW) (ВНУТР. ЧАСТИ)
№
Артикул
Название
Примечание
Количество
|$$2
THE NIKKO DENKI PART NUMBER IS THAT KD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
KD1-23100-0160
ARMATURE ASS'Y
SN: 96999-UP
1шт.
2
KD1-0454-60047
BEARING,BALL¤ FRONT
SN: 96999-UP
1шт.
4
KD0-23230-0210
FIELD COIL ASS'Y
SN: 96999-UP
1шт.
5
KD1-23785-0100
LEAD WIRE ASS'Y
SN: 96999-UP
1шт.
6
KD7-23780-0040
TERMINAL ASS'Y
SN: 96999-UP
1шт.
7
KD0-23310-0680
FRONT BRACKET A.
SN: 96999-UP
1шт.
8
KD7-23351-0140
METAL
SN: 96999-UP
1шт.
9
KD7-23120-0270
SHAFT ASS'Y
SN: 96999-UP
1шт.
10
KD1-0454-60057
BEARING,BALL
SN: 96999-UP
1шт.
11
KD1-23181-0030
STOPPER,PINION
SN: 96999-UP
1шт.
12
KD1-23914-0030
RING,CLIP
SN: 96999-UP
2шт.
13
KD0-23500-0390
CLUTCH ASS'Y,OVER RUNNING
SN: 96999-UP
1шт.
14
KD0-23600-0220
CNETER BRACKET A.
SN: 96999-UP
1шт.
15
KD1-23611-0430
BRACKET,CENTER
SN: 96999-UP
1шт.
16
KD7-23320-0040
SHIFT LEVER ASS'Y
SN: 96999-UP
1шт.
17
KD0-47100-3510
MAGNETIC SWITCH A.
SN: 96999-UP
1шт.
|18
KD7-23700-0370
REAR BRACKET ASS'Y
SN: 96999-UP
1шт.
18
KD1-23711-0071
BRACKET,REAR
SN: 96999-UP
1шт.
19
KD1-23913-0010
SPRING,BRUSH
SN: 96999-UP
4шт.
20
KD0-23750-0120
BRUSH HOLDER A.
SN: 96999-UP
1шт.
22
KD0-23740-0180
BRUSH (-)
SN: 96999-UP
2шт.
23
KD1-23901-0080
BOLT
SN: 96999-UP
2шт.
24
KD0-25000-7050
SWITCH ASS'Y
SN: 96999-UP
1шт.
25
KD7-09210-1390
SEAL ASS'Y,(NOT SHOWN)
SN: 96999-UP
1шт.
|$$2
THE NIKKO DENKI PART NUMBER IS THAT KD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
KD1-23100-0160
ARMATURE ASS'Y
SN: 96999-UP
1шт.
2
KD1-0454-60047
BEARING,BALL¤ FRONT
SN: 96999-UP
1шт.
4
KD0-23230-0210
FIELD COIL ASS'Y
SN: 96999-UP
1шт.
5
KD1-23785-0100
LEAD WIRE ASS'Y
SN: 96999-UP
1шт.
6
KD7-23780-0040
TERMINAL ASS'Y
SN: 96999-UP
1шт.
7
KD0-23310-0680
FRONT BRACKET A.
SN: 96999-UP
1шт.
8
KD7-23351-0140
METAL
SN: 96999-UP
1шт.
9
KD7-23120-0270
SHAFT ASS'Y
SN: 96999-UP
1шт.
10
KD1-0454-60057
BEARING,BALL
SN: 96999-UP
1шт.
11
KD1-23181-0030
STOPPER,PINION
SN: 96999-UP
1шт.
12
KD1-23914-0030
RING,CLIP
SN: 96999-UP
2шт.
13
KD0-23500-0390
CLUTCH ASS'Y,OVER RUNNING
SN: 96999-UP
1шт.
14
KD0-23600-0220
CNETER BRACKET A.
SN: 96999-UP
1шт.
15
KD1-23611-0430
BRACKET,CENTER
SN: 96999-UP
1шт.
16
KD7-23320-0040
SHIFT LEVER ASS'Y
SN: 96999-UP
1шт.
17
KD0-47100-3510
MAGNETIC SWITCH A.
SN: 96999-UP
1шт.
|18
KD7-23700-0370
REAR BRACKET ASS'Y
SN: 96999-UP
1шт.
18
KD1-23711-0071
BRACKET,REAR
SN: 96999-UP
1шт.
19
KD1-23913-0010
SPRING,BRUSH
SN: 96999-UP
4шт.
20
KD0-23750-0120
BRUSH HOLDER A.
SN: 96999-UP
1шт.
22
KD0-23740-0180
BRUSH (-)
SN: 96999-UP
2шт.
23
KD1-23901-0080
BOLT
SN: 96999-UP
2шт.
24
KD0-25000-7050
SWITCH ASS'Y
SN: 96999-UP
1шт.
25
KD7-09210-1390
SEAL ASS'Y,(NOT SHOWN)
SN: 96999-UP
1шт.
|1
600-813-3350
STARTING MOTOR ASS'Y,(5.5KW)
1
KD1-23100-0160
ARMATURE ASS'Y
2
KD1-0454-60047
BEARING,BALL¤ FRONT
3
KD1-0454-62007
BEARING,BALL¤ REAR
4
KD0-23230-0210
FIELD COIL ASS'Y
5
KD1-23785-0100
LEAD WIRE ASS'Y
6
KD7-23780-0040
TERMINAL ASS'Y
7
KD0-23310-0680
FRONT BRACKET A.
8
KD7-23351-0140
METAL
9
KD7-23120-0270
SHAFT ASS'Y
10
KD1-0454-60057
BEARING,BALL
11
KD1-23181-0030
STOPPER,PINION
12
KD1-23914-0030
RING,CLIP
13
KD0-23500-0390
CLUTCH ASS'Y,OVER RUNNING
14
KD0-23600-0220
CNETER BRACKET A.
15
KD1-23611-0430
BRACKET,CENTER
16
KD7-23320-0040
SHIFT LEVER ASS'Y
17
KD0-47100-3510
MAGNETIC SWITCH A.
|18
KD7-23700-0370
REAR BRACKET ASS'Y
18
KD1-23711-0071
BRACKET,REAR
19
KD1-23913-0010
SPRING,BRUSH
20
KD0-23750-0120
BRUSH HOLDER A.
21
KD1-23740-0170
BRUSH (+)
22
KD0-23740-0180
BRUSH (-)
23
KD1-23901-0080
BOLT
24
KD0-25000-7050
SWITCH ASS'Y
25
KD7-09210-1390
SEAL ASS'Y,(NOT SHOWN)
