Артикул
Название
Примечание
Количество
|1
6206-71-1540
INJECTION PUMP ASS'Y
SN: 96999-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 TO A4010-F0A2.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
DK152003-1020
HOUSING
SN: 96999-UP
1шт.
2
DK152100-1120
PISTON
SN: 96999-UP
1шт.
4
DK152105-1600
PLUG
SN: 96999-UP
1шт.
6
DK152111-2820
TAPPET ASS'Y
SN: 96999-UP
1шт.
7
DK152112-0100
ROLLER
SN: 96999-UP
1шт.
8
DK152113-0700
PIN
SN: 96999-UP
1шт.
9
DK152114-0400
GUIDE
SN: 96999-UP
2шт.
10
DK152115-0500
VALVE
SN: 96999-UP
2шт.
12
DK152118-0900
ADAPTER
SN: 96999-UP
1шт.
14
DK152121-0200
RING,SNAP
SN: 96999-UP
1шт.
16
DK152300-5920
BOLT,JOINT
SN: 96999-UP
1шт.
18
DK029711-4310
EYE
SN: 96999-UP
1шт.
|1
6206-71-1540
INJECTION PUMP ASS'Y
SN: 96999-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 TO A4010-F0A2.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
DK152003-1020
HOUSING
SN: 96999-UP
1шт.
2
DK152100-1120
PISTON
SN: 96999-UP
1шт.
4
DK152105-1600
PLUG
SN: 96999-UP
1шт.
6
DK152111-2820
TAPPET ASS'Y
SN: 96999-UP
1шт.
7
DK152112-0100
ROLLER
SN: 96999-UP
1шт.
8
DK152113-0700
PIN
SN: 96999-UP
1шт.
9
DK152114-0400
GUIDE
SN: 96999-UP
2шт.
10
DK152115-0500
VALVE
SN: 96999-UP
2шт.
12
DK152118-0900
ADAPTER
SN: 96999-UP
1шт.
14
DK152121-0200
RING,SNAP
SN: 96999-UP
1шт.
16
DK152300-5920
BOLT,JOINT
SN: 96999-UP
1шт.
18
DK029711-4310
EYE
SN: 96999-UP
1шт.
|1
6206-71-1540
INJECTION PUMP ASS'Y
|1
DK105220-5610
FEED PUMP ASS'Y
1
DK152003-1020
HOUSING
2
DK152100-1120
PISTON
3
DK152102-1600
SPRING
4
DK152105-1600
PLUG
5
DK029332-6030
GASKET
6
DK152111-2820
TAPPET ASS'Y
7
DK152112-0100
ROLLER
8
DK152113-0700
PIN
9
DK152114-0400
GUIDE
10
DK152115-0500
VALVE
11
DK152116-0200
SPRING
12
DK152118-0900
ADAPTER
13
DK029631-6060
O-RING
14
DK152121-0200
RING,SNAP
15
DK152200-5420
PUMP,PRIMING
16
DK152300-5920
BOLT,JOINT
17
DK029731-4680
BOLT,JOINT
18
DK029711-4310
EYE
19
DK029341-4130
GASKET
20
DK152320-0100
COVER
