Запчасти Komatsu 2D68E-N3A ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ВНУТР. ЧАСТИ)
№
Артикул
Название
Примечание
Количество
|1
6206-71-1540
INJECTION PUMP ASS'Y
SN: 96999-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 TO A4010-F0A2.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105400-7620
GOVERNOR ASS'Y
SN: 96999-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D0A2 AND A4010-E0A2.
-1шт.
2
DK154500-1020
COVER
SN: 96999-UP
1шт.
3
DK154321-0400
BUSHING
SN: 96999-UP
1шт.
4
DK154031-3000
SCREW
SN: 96999-UP
1шт.
5
DK139206-0600
NUT
SN: 96999-UP
1шт.
6
DK154036-0300
PLUG
SN: 96999-UP
2шт.
7
DK020106-5040
BOLT
SN: 96999-UP
2шт.
8
DK154010-0100
SCREW
SN: 96999-UP
1шт.
9
DK020106-3840
BOLT
SN: 96999-UP
4шт.
10
DK154063-5100
COVER
SN: 96999-UP
1шт.
11
DK029020-6260
BOLT
SN: 96999-UP
2шт.
12
DK020006-2040
BOLT
SN: 96999-UP
1шт.
13
DK020006-1640
BOLT
SN: 96999-UP
1шт.
15
DK154158-1520
CAPSULE,SPRING
SN: 96999-UP
1шт.
16
DK154011-1700
NUT
SN: 96999-UP
1шт.
22
DK016010-1640
RING,SNAP
SN: 96999-UP
2шт.
30
DK154237-0100
PIN
SN: 96999-UP
1шт.
31
DK154341-9520
LEVER
SN: 96999-UP
1шт.
32
DK154304-5800
LEVER
SN: 96999-UP
1шт.
33
DK020006-1640
BOLT
SN: 96999-UP
1шт.
34
DK029631-0030
O-RING
SN: 96999-UP
1шт.
35
DK154322-0100
CAP
SN: 96999-UP
1шт.
42
DK154358-7200
BRACKET
SN: 96999-UP
1шт.
|1
6206-71-1540
INJECTION PUMP ASS'Y
SN: 96999-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 TO A4010-F0A2.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105400-7620
GOVERNOR ASS'Y
SN: 96999-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D0A2 AND A4010-E0A2.
-1шт.
2
DK154500-1020
COVER
SN: 96999-UP
1шт.
3
DK154321-0400
BUSHING
SN: 96999-UP
1шт.
4
DK154031-3000
SCREW
SN: 96999-UP
1шт.
5
DK139206-0600
NUT
SN: 96999-UP
1шт.
6
DK154036-0300
PLUG
SN: 96999-UP
2шт.
7
DK020106-5040
BOLT
SN: 96999-UP
2шт.
8
DK154010-0100
SCREW
SN: 96999-UP
1шт.
9
DK020106-3840
BOLT
SN: 96999-UP
4шт.
10
DK154063-5100
COVER
SN: 96999-UP
1шт.
11
DK029020-6260
BOLT
SN: 96999-UP
2шт.
12
DK020006-2040
BOLT
SN: 96999-UP
1шт.
13
DK020006-1640
BOLT
SN: 96999-UP
1шт.
15
DK154158-1520
CAPSULE,SPRING
SN: 96999-UP
1шт.
16
DK154011-1700
NUT
SN: 96999-UP
1шт.
22
DK016010-1640
RING,SNAP
SN: 96999-UP
2шт.
30
DK154237-0100
PIN
SN: 96999-UP
1шт.
31
DK154341-9520
LEVER
SN: 96999-UP
1шт.
32
DK154304-5800
LEVER
SN: 96999-UP
1шт.
33
DK020006-1640
BOLT
SN: 96999-UP
1шт.
34
DK029631-0030
O-RING
SN: 96999-UP
1шт.
35
DK154322-0100
CAP
SN: 96999-UP
1шт.
42
DK154358-7200
BRACKET
SN: 96999-UP
1шт.
|1
6206-71-1540
INJECTION PUMP ASS'Y
|1
DK105400-7620
GOVERNOR ASS'Y
1
DK154011-0100
NUT,LOCK
2
DK154500-1020
COVER
3
DK154321-0400
BUSHING
4
DK154031-3000
SCREW
5
DK139206-0600
NUT
6
DK154036-0300
PLUG
7
DK020106-5040
BOLT
8
DK154010-0100
SCREW
9
DK020106-3840
BOLT
10
DK154063-5100
COVER
11
DK029020-6260
BOLT
12
DK020006-2040
BOLT
13
DK020006-1640
BOLT
14
DK154150-2700
SPRING,GOVERNOR
15
DK154158-1520
CAPSULE,SPRING
16
DK154011-1700
NUT
17
DK026512-1540
GASKET
18
DK154159-1200
NUT,CAP
19
DK154200-7120
LEVER,SWIVEL
20
DK154204-3000
BUSHING
21
DK029631-8020
O-RING
22
DK016010-1640
RING,SNAP
23
DK139611-0000
SEAL,OIL
24
DK139411-0000
SHIM¤ 0.40MM
25
DK029311-1090
SHIM¤ 0.30MM
26
DK154204-3100
BUSHING
27
DK025803-1310
KEY¤ 13MM
28
DK154206-2800
COLLAR
29
DK154206-0200
WASHER¤ 1.0MM
30
DK154237-0100
PIN
31
DK154341-9520
LEVER
32
DK154304-5800
LEVER
33
DK020006-1640
BOLT
34
DK029631-0030
O-RING
35
DK154322-0100
CAP
36
DK154327-7600
SPRING
37
DK029311-0520
SHIM¤ 0.2MM
|37
DK029311-0530
SHIM¤ 0.25MM
|37
DK029311-0540
SHIM¤ 0.3MM
|37
DK029311-0550
SHIM¤ 0.35MM
|37
DK029311-0560
SHIM¤ 0.4MM
|37
DK029311-0570
SHIM¤ 0.5MM
38
DK154350-7800
GASKET
39
DK029635-2020
O-RING
40
DK026506-1040
GASKET
41
DK154035-1600
NUT,CAP
42
DK154358-7200
BRACKET
