Запчасти Komatsu 2D68E-N3A ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ВНУТР. ЧАСТИ)

Схема запчастей Komatsu 2D68E-N3A - ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ВНУТР. ЧАСТИ)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27

Артикул

Название

Примечание

Количество

|1

6206-71-1540

INJECTION PUMP ASS'Y

SN: 96999-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 TO A4010-F0A2.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105400-7620

GOVERNOR ASS'Y

SN: 96999-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D0A2 AND A4010-E0A2.

-1шт.

1

DK154000-6300

HOUSING

SN: 96999-UP

1шт.

2

DK029632-5070

O-RING

SN: 96999-UP

1шт.

3

DK154007-2900

PLUG

SN: 96999-UP

1шт.

4

DK154007-0200

ADAPTER

SN: 96999-UP

1шт.

5

DK020018-1840

BOLT

SN: 96999-UP

1шт.

6

DK154350-1900

PLATE

SN: 96999-UP

1шт.

7

DK029010-6810

BOLT

SN: 96999-UP

6шт.

8

DK154010-0100

SCREW

SN: 96999-UP

1шт.

9

DK154011-0100

NUT,LOCK

SN: 96999-UP

1шт.

10

DK155404-5300

CAP

SN: 96999-UP

1шт.

11

DK154101-0120

FLYWEIGHT ASS'Y

SN: 96999-UP

1шт.

12

DK029321-2020

WASHER,SPRING

SN: 96999-UP

1шт.

13

DK029231-2030

NUT

SN: 96999-UP

1шт.

14

DK154123-0120

SLEEVE

SN: 96999-UP

1шт.

15

DK029801-0030

BEARING

SN: 96999-UP

1шт.

16

DK029311-0010

SHIM¤ 0.20MM

SN: 96999-UP

-2шт.

|16

DK029311-0180

SHIM¤ 0.30MM

SN: 96999-UP

-2шт.

|16

DK029311-0190

SHIM¤ 0.40MM

SN: 96999-UP

-2шт.

|16

DK139410-0000

SHIM¤ 0.50MM

SN: 96999-UP

-2шт.

|16

DK029311-0210

SHIM¤ 1.00MM

SN: 96999-UP

-2шт.

|16

DK139410-0100

SHIM¤ 1.50MM

SN: 96999-UP

-2шт.

|16

DK139410-3000

SHIM¤ 2.00MM

SN: 96999-UP

-2шт.

|16

DK139410-3100

SHIM¤ 3.00MM

SN: 96999-UP

-2шт.

|16

DK139410-3200

SHIM¤ 4.00MM

SN: 96999-UP

-2шт.

17

DK154154-0701

SPRING

SN: 96999-UP

1шт.

18

DK154185-1020

CAPSULE,SPRING

SN: 96999-UP

1шт.

19

DK029201-6080

NUT

SN: 96999-UP

1шт.

20

DK154210-0920

GUIDE LEVER ASS'Y

SN: 96999-UP

1шт.

21

DK154230-3920

LINK

SN: 96999-UP

1шт.

22

DK016010-0540

RING,SNAP

SN: 96999-UP

1шт.

23

DK154236-1500

LEVER,TENSION

SN: 96999-UP

1шт.

24

DK154326-5020

LEVER ASS'Y

SN: 96999-UP

1шт.

25

DK154350-7700

GASKET

SN: 96999-UP

1шт.

26

DK154172-3520

CAPSULE,SPRING

SN: 96999-UP

1шт.

27

DK029201-6010

NUT

SN: 96999-UP

1шт.

|1

6206-71-1540

INJECTION PUMP ASS'Y

SN: 96999-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 TO A4010-F0A2.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105400-7620

GOVERNOR ASS'Y

SN: 96999-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D0A2 AND A4010-E0A2.

-1шт.

1

DK154000-6300

HOUSING

SN: 96999-UP

1шт.

2

DK029632-5070

O-RING

SN: 96999-UP

1шт.

3

DK154007-2900

PLUG

SN: 96999-UP

1шт.

4

DK154007-0200

ADAPTER

SN: 96999-UP

1шт.

5

DK020018-1840

BOLT

SN: 96999-UP

1шт.

6

DK154350-1900

PLATE

SN: 96999-UP

1шт.

7

DK029010-6810

BOLT

SN: 96999-UP

6шт.

8

DK154010-0100

SCREW

SN: 96999-UP

1шт.

9

DK154011-0100

NUT,LOCK

SN: 96999-UP

1шт.

10

DK155404-5300

CAP

SN: 96999-UP

1шт.

11

DK154101-0120

FLYWEIGHT ASS'Y

SN: 96999-UP

1шт.

12

DK029321-2020

WASHER,SPRING

SN: 96999-UP

1шт.

13

DK029231-2030

NUT

SN: 96999-UP

1шт.

14

DK154123-0120

SLEEVE

SN: 96999-UP

1шт.

15

DK029801-0030

BEARING

SN: 96999-UP

1шт.

16

DK029311-0010

SHIM¤ 0.20MM

SN: 96999-UP

-2шт.

|16

DK029311-0180

SHIM¤ 0.30MM

SN: 96999-UP

-2шт.

|16

DK029311-0190

SHIM¤ 0.40MM

SN: 96999-UP

-2шт.

|16

DK139410-0000

SHIM¤ 0.50MM

SN: 96999-UP

-2шт.

|16

DK029311-0210

SHIM¤ 1.00MM

SN: 96999-UP

-2шт.

|16

DK139410-0100

SHIM¤ 1.50MM

SN: 96999-UP

-2шт.

|16

DK139410-3000

SHIM¤ 2.00MM

SN: 96999-UP

-2шт.

|16

DK139410-3100

SHIM¤ 3.00MM

SN: 96999-UP

-2шт.

|16

DK139410-3200

SHIM¤ 4.00MM

SN: 96999-UP

-2шт.

17

DK154154-0701

SPRING

SN: 96999-UP

1шт.

18

DK154185-1020

CAPSULE,SPRING

SN: 96999-UP

1шт.

19

DK029201-6080

NUT

SN: 96999-UP

1шт.

20

DK154210-0920

GUIDE LEVER ASS'Y

SN: 96999-UP

1шт.

21

DK154230-3920

LINK

SN: 96999-UP

1шт.

22

DK016010-0540

RING,SNAP

SN: 96999-UP

1шт.

23

DK154236-1500

LEVER,TENSION

SN: 96999-UP

1шт.

24

DK154326-5020

LEVER ASS'Y

SN: 96999-UP

1шт.

25

DK154350-7700

GASKET

SN: 96999-UP

1шт.

26

DK154172-3520

CAPSULE,SPRING

SN: 96999-UP

1шт.

27

DK029201-6010

NUT

SN: 96999-UP

1шт.

|1

6206-71-1540

INJECTION PUMP ASS'Y

|1

DK105400-7620

GOVERNOR ASS'Y

1

DK154000-6300

HOUSING

2

DK029632-5070

O-RING

3

DK154007-2900

PLUG

4

DK154007-0200

ADAPTER

5

DK020018-1840

BOLT

6

DK154350-1900

PLATE

7

DK029010-6810

BOLT

8

DK154010-0100

SCREW

9

DK154011-0100

NUT,LOCK

10

DK155404-5300

CAP

11

DK154101-0120

FLYWEIGHT ASS'Y

12

DK029321-2020

WASHER,SPRING

13

DK029231-2030

NUT

14

DK154123-0120

SLEEVE

15

DK029801-0030

BEARING

16

DK029311-0010

SHIM¤ 0.20MM

|16

DK029311-0180

SHIM¤ 0.30MM

|16

DK029311-0190

SHIM¤ 0.40MM

|16

DK139410-0000

SHIM¤ 0.50MM

|16

DK029311-0210

SHIM¤ 1.00MM

|16

DK139410-0100

SHIM¤ 1.50MM

|16

DK139410-3000

SHIM¤ 2.00MM

|16

DK139410-3100

SHIM¤ 3.00MM

|16

DK139410-3200

SHIM¤ 4.00MM

17

DK154154-0701

SPRING

18

DK154185-1020

CAPSULE,SPRING

19

DK029201-6080

NUT

20

DK154210-0920

GUIDE LEVER ASS'Y

21

DK154230-3920

LINK

22

DK016010-0540

RING,SNAP

23

DK154236-1500

LEVER,TENSION

24

DK154326-5020

LEVER ASS'Y

25

DK154350-7700

GASKET

26

DK154172-3520

CAPSULE,SPRING

27

DK029201-6010

NUT

Выбрано товаров: 117
