Запчасти Komatsu 2D68E-N3A ТОПЛ. НАСОС (НАСОС) (/) (ВНУТР. ЧАСТИ)
№
Артикул
Название
Примечание
Количество
|1
6206-71-1540
INJECTION PUMP ASS'Y
SN: 96999-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 TO A4010-F0A2.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK101069-9440
PUMP ASS'Y
SN: 96999-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 AND A4010-C0A2.
-1шт.
1
DK131073-7020
HOUSING
SN: 96999-UP
1шт.
3
DK131400-0100
ADAPTER
SN: 96999-UP
1шт.
4
DK131420-0420
BOLT
SN: 96999-UP
1шт.
5
DK131028-6020
COVER
SN: 96999-UP
1шт.
6
DK131011-0800
GASKET
SN: 96999-UP
1шт.
7
DK131017-1000
SCREW
SN: 96999-UP
2шт.
11
DK131371-3700
CAMSHAFT
SN: 96999-UP
1шт.
|12
DK028201-7020
BEARING
SN: 96999-UP
-2шт.
|13
DK028202-0020
BEARING
SN: 96999-UP
-2шт.
14
DK131302-1300
RING
SN: 96999-UP
1шт.
16
DK029312-0310
SHIM¤ 0.10MM
SN: 96999-UP
-2шт.
|16
DK029312-0320
SHIM¤ 0.12MM
SN: 96999-UP
-2шт.
|16
DK029312-0330
SHIM¤ 0.14MM
SN: 96999-UP
-2шт.
|16
DK029312-0340
SHIM¤ 0.16MM
SN: 96999-UP
-2шт.
|16
DK029312-0350
SHIM¤ 0.18MM
SN: 96999-UP
-2шт.
|16
DK029312-0360
SHIM¤ 0.3MM
SN: 96999-UP
-2шт.
|16
DK029312-0370
SHIM¤ 0.5MM
SN: 96999-UP
-2шт.
|16
DK029312-0380
SHIM¤ 1.0MM
SN: 96999-UP
-2шт.
17
DK029311-7010
SHIM¤ 0.1MM
SN: 96999-UP
-2шт.
|17
DK029311-7020
SHIM¤ 0.12MM
SN: 96999-UP
-2шт.
|17
DK029311-7030
SHIM¤ 0.14MM
SN: 96999-UP
-2шт.
|17
DK029311-7040
SHIM¤ 0.16MM
SN: 96999-UP
-2шт.
|17
DK029311-7050
SHIM¤ 0.18MM
SN: 96999-UP
-2шт.
|17
DK029311-7090
SHIM¤ 0.3MM
SN: 96999-UP
-2шт.
|17
DK029311-7060
SHIM¤ 0.5MM
SN: 96999-UP
-2шт.
|17
DK029311-7210
SHIM¤ 0.7MM
SN: 96999-UP
-2шт.
|17
DK029311-7070
SHIM¤ 1.0MM
SN: 96999-UP
-2шт.
|17
DK029311-7220
SHIM¤ 1.4MM
SN: 96999-UP
-2шт.
|17
DK139417-0000
SHIM¤ 2.40MM
SN: 96999-UP
-2шт.
18
DK131306-1000
BEARING,CENTER
SN: 96999-UP
1шт.
19
DK029050-5010
SCREW
SN: 96999-UP
2шт.
20
DK026505-0940
GASKET
SN: 96999-UP
2шт.
22
DK131330-1800
COVER
SN: 96999-UP
1шт.
23
DK020006-2040
BOLT
SN: 96999-UP
4шт.
24
DK131321-1700
GASKET
SN: 96999-UP
1шт.
25
DK029470-4030
KEY
SN: 96999-UP
1шт.
26
DK131401-0020
BOLT,EYE
SN: 96999-UP
1шт.
|1
6206-71-1540
INJECTION PUMP ASS'Y
SN: 96999-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 TO A4010-F0A2.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK101069-9440
PUMP ASS'Y
SN: 96999-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0A2 AND A4010-C0A2.
-1шт.
1
DK131073-7020
HOUSING
SN: 96999-UP
1шт.
3
DK131400-0100
ADAPTER
SN: 96999-UP
1шт.
4
DK131420-0420
BOLT
SN: 96999-UP
1шт.
5
DK131028-6020
COVER
SN: 96999-UP
1шт.
6
DK131011-0800
GASKET
SN: 96999-UP
1шт.
7
DK131017-1000
SCREW
SN: 96999-UP
2шт.
11
DK131371-3700
CAMSHAFT
SN: 96999-UP
1шт.
|12
DK028201-7020
BEARING
SN: 96999-UP
-2шт.
|13
DK028202-0020
BEARING
SN: 96999-UP
-2шт.
14
DK131302-1300
RING
SN: 96999-UP
1шт.
16
DK029312-0310
SHIM¤ 0.10MM
SN: 96999-UP
-2шт.
|16
DK029312-0320
SHIM¤ 0.12MM
SN: 96999-UP
-2шт.
|16
DK029312-0330
SHIM¤ 0.14MM
SN: 96999-UP
-2шт.
|16
DK029312-0340
SHIM¤ 0.16MM
SN: 96999-UP
-2шт.
|16
DK029312-0350
SHIM¤ 0.18MM
SN: 96999-UP
-2шт.
|16
DK029312-0360
SHIM¤ 0.3MM
SN: 96999-UP
-2шт.
|16
DK029312-0370
SHIM¤ 0.5MM
SN: 96999-UP
-2шт.
|16
DK029312-0380
SHIM¤ 1.0MM
SN: 96999-UP
-2шт.
17
DK029311-7010
SHIM¤ 0.1MM
SN: 96999-UP
-2шт.
|17
DK029311-7020
SHIM¤ 0.12MM
SN: 96999-UP
-2шт.
|17
DK029311-7030
SHIM¤ 0.14MM
SN: 96999-UP
-2шт.
|17
DK029311-7040
SHIM¤ 0.16MM
SN: 96999-UP
-2шт.
|17
DK029311-7050
SHIM¤ 0.18MM
SN: 96999-UP
-2шт.
|17
DK029311-7090
SHIM¤ 0.3MM
SN: 96999-UP
-2шт.
|17
DK029311-7060
SHIM¤ 0.5MM
SN: 96999-UP
-2шт.
|17
DK029311-7210
SHIM¤ 0.7MM
SN: 96999-UP
-2шт.
|17
DK029311-7070
SHIM¤ 1.0MM
SN: 96999-UP
-2шт.
|17
DK029311-7220
SHIM¤ 1.4MM
SN: 96999-UP
-2шт.
|17
DK139417-0000
SHIM¤ 2.40MM
SN: 96999-UP
-2шт.
18
DK131306-1000
BEARING,CENTER
SN: 96999-UP
1шт.
19
DK029050-5010
SCREW
SN: 96999-UP
2шт.
20
DK026505-0940
GASKET
SN: 96999-UP
2шт.
22
DK131330-1800
COVER
SN: 96999-UP
1шт.
23
DK020006-2040
BOLT
SN: 96999-UP
4шт.
24
DK131321-1700
GASKET
SN: 96999-UP
1шт.
25
DK029470-4030
KEY
SN: 96999-UP
1шт.
26
DK131401-0020
BOLT,EYE
SN: 96999-UP
1шт.
|1
6206-71-1540
INJECTION PUMP ASS'Y
|1
DK101069-9440
PUMP ASS'Y
1
DK131073-7020
HOUSING
2
DK029040-6020
STUD
3
DK131400-0100
ADAPTER
4
DK131420-0420
BOLT
5
DK131028-6020
COVER
6
DK131011-0800
GASKET
7
DK131017-1000
SCREW
8
DK029340-6020
GASKET
9
DK139206-0400
NUT
10
DK029633-1010
O-RING
11
DK131371-3700
CAMSHAFT
12
DK016630-2030
BEARING
|12
DK028201-7020
BEARING
13
DK016640-2030
BEARING
|13
DK028202-0020
BEARING
14
DK131302-1300
RING
15
DK131302-1700
RING
16
DK029312-0310
SHIM¤ 0.10MM
|16
DK029312-0320
SHIM¤ 0.12MM
|16
DK029312-0330
SHIM¤ 0.14MM
|16
DK029312-0340
SHIM¤ 0.16MM
|16
DK029312-0350
SHIM¤ 0.18MM
|16
DK029312-0360
SHIM¤ 0.3MM
|16
DK029312-0370
SHIM¤ 0.5MM
|16
DK029312-0380
SHIM¤ 1.0MM
17
DK029311-7010
SHIM¤ 0.1MM
|17
DK029311-7020
SHIM¤ 0.12MM
|17
DK029311-7030
SHIM¤ 0.14MM
|17
DK029311-7040
SHIM¤ 0.16MM
|17
DK029311-7050
SHIM¤ 0.18MM
|17
DK029311-7090
SHIM¤ 0.3MM
|17
DK029311-7060
SHIM¤ 0.5MM
|17
DK029311-7210
SHIM¤ 0.7MM
|17
DK029311-7070
SHIM¤ 1.0MM
|17
DK029311-7220
SHIM¤ 1.4MM
|17
DK139417-0000
SHIM¤ 2.40MM
18
DK131306-1000
BEARING,CENTER
19
DK029050-5010
SCREW
20
DK026505-0940
GASKET
21
DK029622-0190
SEAL,OIL
22
DK131330-1800
COVER
23
DK020006-2040
BOLT
24
DK131321-1700
GASKET
25
DK029470-4030
KEY
26
DK131401-0020
BOLT,EYE
27
DK029341-4130
GASKET
28
DK029637-5020
O-RING
29
DK029731-0120
BOLT,EYE
30
DK029341-0110
GASKET
