Запчасти Komatsu D37P-5A МАРКИРОВКА (ФРАНЦИЯ)(№-) МАРКИРОВКА

1

09637-30262

PLATE, INSTRUCTION,AIR CLEANER

SN: 3001-UP

1шт.

2

09667-A0481

PLATE, SAFETY,ENGINE ROOM

SN: 3927-UP

1шт.

3

09653-A0481

PLATE, SAFETY,RADIATOR WARNING

SN: 3927-UP

1шт.

4

114-98-44250

PLATE, OPERATING,PARKING BRAKE LEVER LOCK

SN: 3001-UP

3шт.

5

09651-A0641

PLATE, SAFETY,BEFORE OPERATING

SN: 3927-UP

1шт.

6

09652-51101

PLATE, CAUTION,FUEL TANK

SN: 3001-UP

1шт.

7

114-98-44421

PLATE, MARK,KOMATSU, L.H.

SN: 3937-UP

1шт.

7

114-98-44420

PLATE, MARK,KOMATSU, L.H.

SN: 3001-3936

1шт.

7

114-98-44431

PLATE, MARK,KOMATSU, R.H.

SN: 3937-UP

1шт.

7

114-98-44430

PLATE, MARK,KOMATSU, R.H.

SN: 3001-3936

1шт.

8

09602-51635

PLATE, NAME,(LIMITED SUPPLY)

SN: 3001-UP

1шт.

8

04418-13060

SCREW

SN: 3001-UP

4шт.

9

11G-98-42971

PLATE, MARK,D37P

SN: 3001-UP

2шт.

10

09690-C0355

PLATE, MARK,KOMATSU

SN: 3661-UP

1шт.

11

09683-0000E

PLATE, OPERATING,STARTING SWITCH

SN: 3941-UP

1шт.

11

09683-51060

PLATE, OPERATING,STARTING SWITCH

SN: 3001-3930

1шт.

12

09653-A0481

PLATE, SAFETY,HYDRAULIC TANK

SN: 3927-UP

1шт.

13

103-98-21451

PLATE, CAUTION,HYDRAULIC FILTER

SN: 3001-UP

1шт.

14

114-98-51181

OIL CHART

SN: 3941-UP

1шт.

14

114-98-51180

CHART, OIL

SN: 3661-3940

1шт.

15

114-98-44250

PLATE, OPERATING,BLADE CONTROL LEVER LOCK

SN: 3001-UP

3шт.

16

114-98-51130

PLATE, OPERATING,BLADE CONTROL LEVER

SN: 3661-UP

1шт.

17

09173-05000

PLATE, SAFETY,INSPECTION AND MAINTENANCE

SN: 3001-UP

1шт.

18

114-98-44250

PLATE, OPERATING,T/M CONTROL LEVER LOCK

SN: 3001-UP

3шт.

19

09657-05011

PLATE, SAFETY,TRACK ADJUSTING

SN: 3001-UP

1шт.

20

09654-B0641

PLATE, SAFETY,STARTING AND AFTER OPERATING

SN: 3927-UP

1шт.

21

114-98-44170

PLATE, OPERATING,STEERING CONTROL LEVER

SN: 3001-UP

1шт.

22

114-98-44180

PLATE, OPERATING,STEERING CONTROL LEVER

SN: 3001-UP

1шт.

23

09802-B0750

PLATE, SAFETY,BEFORE DRIVING

SN: 3927-UP

1шт.

24

09806-B1201

PLATE, SAFETY,KEEP A SAFE DISTANCE

SN: 3927-UP

2шт.

25

09808-A0881

PLATE, SAFETY,BATTERY CABLE

SN: 3927-UP

1шт.

26

09963-A1640

TAG,DO NOT OPERATE

SN: 3927-UP

1шт.

27

09669-0000E

PLATE, CAUTION

SN: 3950-UP

1шт.
