Запчасти Komatsu D37P-5A МАРКИРОВКА (АНГЛ.)(№-) МАРКИРОВКА

1

09637-30161

PLATE¤ INSTRUCTION,AIR CLEANER

SN: 3001-UP

1шт.

2

09667-03000

PLATE¤ SAFETY,ENGINE ROOM

SN: 3001-UP

1шт.

3

09668-03000

PLATE¤ SAFETY,RADIATOR WARNING

SN: 3001-UP

1шт.

4

114-98-44250

PLATE¤ OPERATING,PARKING BRAKE LEVER LOCK

SN: 3001-UP

1шт.

5

09651-03000

PLATE¤ SAFETY,BEFORE OPERATING

SN: 3001-UP

1шт.

6

09652-30101

PLATE¤ CAUTION,FUEL TANK

SN: 3001-UP

1шт.

7

114-98-44420

PLATE¤ MARK,KOMATSU¤ L.H.

SN: 3001-UP

1шт.

|7

114-98-44430

PLATE¤ MARK,KOMATSU¤ R.H.

SN: 3001-UP

1шт.

8

09601-00835

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 3001-UP

1шт.

|8

04418-13060

SCREW

SN: 3001-UP

4шт.

9

11G-98-42971

PLATE¤ MARK,D37P

SN: 3001-UP

2шт.

10

09690-C0355

PLATE¤ MARK,KOMATSU

SN: 3661-UP

1шт.

|10

09690-C0355

PLATE¤ MARK,KOMATSU (FOR USA)

SN: 3220-UP

1шт.

11

09683-30060

PLATE¤ OPERATING,STARTING SWITCH

SN: 3001-UP

1шт.

12

09653-03000

PLATE¤ SAFETY,HYDRAULIC TANK

SN: 3001-UP

1шт.

13

103-98-21351

PLATE¤ CAUTION,HYDRAULIC FILTER

SN: 3001-UP

1шт.

14

114-98-51150

CHART¤ OIL

SN: 3661-UP

1шт.

15

114-98-44250

PLATE¤ OPERATING,BLADE CONTROL LEVER LOCK

SN: 3001-UP

1шт.

16

114-98-51130

PLATE¤ OPERATING,BLADE CONTROL LEVER

SN: 3661-UP

1шт.

17

09173-03000

PLATE¤ SAFETY,INSPECTION AND MAINTENANCE

SN: 3001-UP

1шт.

18

114-98-44250

PLATE¤ OPERATING,T/M CONTROL LEVER LOCK

SN: 3001-UP

1шт.

19

09657-03010

PLATE¤ SAFETY,TRACK ADJUSTING

SN: 3001-UP

1шт.

20

114-98-44510

PLATE¤ SAFETY,STARTING AND AFTER OPERATING

SN: 3001-UP

1шт.

21

114-98-44170

PLATE¤ OPERATING,STEERING CONTROL LEVER

SN: 3001-UP

1шт.

22

114-98-44180

PLATE¤ OPERATING,STEERING CONTROL LEVER

SN: 3001-UP

1шт.

23

114-98-44220

PLATE¤ OPERATING,GEAR SHIFT CONTROL LEVER

SN: 3001-UP

1шт.

24

09664-30081

PLATE¤ INSTRUCTION,BATTERY (FOR USA)

SN: 3001-UP

1шт.

25

09664-30068

PLATE¤ INSTRUCTION,BATTERY DISTRIBUTOR (FOR USA)

SN: 3001-UP

1шт.
