Запчасти Komatsu D375A-5D ОСНОВН. РАМА ОСНОВН. РАМА И КОМПОНЕНТЫ

1

195-21-41213

FRAME A'SSY

SN: 17743-UP

1шт.

2

195-21-32451

CAP

SN: 17743-UP

2шт.

3

11S-70-11170

BOLT

SN: 17743-UP

8шт.

4

01643-32060

WASHER

SN: 17743-UP

8шт.

5

195-21-32510

BUSHING

SN: 17743-UP

2шт.

6

195-21-32522

BUSHING

SN: 17743-UP

2шт.

7

195-50-41140

BUSHING

SN: 17743-UP

2шт.

8

195-21-32670

BUSHING

SN: 17743-UP

8шт.

9

195-21-32480

BUSHING

SN: 17743-UP

4шт.

1

195-61-51510

BRACKET

2

01010-81225

BOLT

3

01643-31232

WASHER

4

07095-00524

CUSHION

5

07094-30518

CLAMP

6

01010-81270

BOLT

7

01643-31232

WASHER

8

195-49-37131

BRACKET

9

01010-81225

BOLT

10

01643-31232

WASHER

11

07095-00524

CUSHION

12

07094-30518

CLAMP

13

01010-81270

BOLT

14

01643-31232

WASHER

15

205-62-53780

COVER

16

08034-00536

BAND

17

01010-81230

BOLT

18

01643-31232

WASHER

19

07123-10515

HOSE

20

195-61-42321

FLANGE

21

195-61-42430

HOSE

22

07376-50522

PLUG

23

195-61-42330

NIPPLE

24

07002-52434

O-RING

25

195-50-22132

COVER

26

195-61-42350

ELBOW

27

07002-52434

O-RING

28

07221-20522

NUT

29

07222-00515

PLUG

30

01010-81695

BOLT

31

01643-31645

WASHER

32

01011-81615

BOLT

33

01643-31645

WASHER

34

195-30-62531

COVER

35

01010-61635

BOLT

36

01643-31645

WASHER

37

195-30-62510

PLATE

38

01010-61635

BOLT

39

01643-31645

WASHER
